V100-17-CAN Technical Specifications
CANbus port
Nodes
Power requirements
Galvanic isolation
Cable type
Cable length/baud rate
Weight
8
V130 COM Modules: V100-17-CAN, V100-17-RS4/X, V100-17-ET2
1
CANopen
127
24VDC (±4%), 40mA max. per unit
Yes, between CANbus and controller
Twisted-pair; DeviceNet® thick shielded twisted pair cable is
recommended.
25 m 1 Mbit/s
100 m 500 Kbit/s
250 m 250 Kbit/s
500 m 125 Kbit/s
500 m 100 Kbit/s
1000 m* 50 Kbit/s
1000 m* 20 Kbit/s
9.2g (0.32 oz)
Unitronics' CANbus protocols
60
* If you require cable lengths over 500
meters, contact technical support.
