Unitronics Uni-I/O UIA-0800NH Installation Manual

Uni-I/O™
Modules
Uni-I/O™ is a family of Input/Output modules that are compatible with the UniStream
control platform.
This guide provides basic installation information for the UIA-0800NH module.
Technical specifications may be downloaded from the Unitronics website.
®
The UniStream platform
comprises CPU controllers, HMI
panels, and local I/O modules
that snap together to form an
all-in-one Programmable Logic
Controller (PLC).
Install Uni-I/O™ modules:
 Onto the back of any
®
UniStream HMI Panel
comprising a CPU-for-Panel.
 Onto a DIN-rail, using a
Local Expansion Kit.
The maximum number of Uni-I/O™ modules that can be connected to a single CPU
controller is limited. For details, please refer to the specification sheets of the UniStream
CPU or any of the relevant Local Expansion Kits.

Before You Begin

Before installing the device, the installer must:
 Read and understand this document.
 Verify the Kit Contents.

Installation option requirements

If you are installing a Uni-I/O™ module onto:
®
 A UniStream HMI Panel; the Panel must comprise a CPU-for-Panel, installed according
to the CPU-for-Panel installation guide.
 A DIN-rail; you must use a Local Expansion Kit, available by separate order, to integrate
the Uni-I/O™ modules on the DIN-rail into a UniStream
Alert Symbols and General Restrictions
When any of the following symbols appear, read the associated information carefully.
Symbol Meaning
Danger
Warning
Caution Caution
 All examples and diagrams are intended to aid understanding, and do not guarantee
Unitronics
Installation Guide
UIA-0800NH
Description
The identified danger causes physical and property damage.
The identified danger could cause physical and property damage.
Use caution.
®
control system.
SCAN
to download
®
®
1
