CHV-TSTAT-FCU-HOTEL
1
Mounting
Mount the Crestron
®
thermostat
directly to drywall or to a single-gang
box in accordance with accepted
building codes and practices. If
using the single-gang box, be sure
to fill it with thermal insulation
material.
For additional details and installation
options, refer to the
CHV-TSTAT-FCU-HOTEL
Operations & Installation Guide
(Doc. 7543) at
www.crestron.com/manuals.
1
For details, refer to the CHV-TSTAT-FCU-HOTEL Operations & Installation
Guide, Doc. 7543.
QUICKSTART DOC. 7544A (2037050) 04.14
Heating and Cooling Thermostat (Fan Coil Unit)
2
Wiring
Connect the thermostat using the wiring configurations shown below as a guide. Place the jumper on the lower two
pins. For more information, refer to the CHV-TSTAT-FCU-HOTEL Operations & Installation Guide (Doc. 7543).
TOP
www.crestron.com
Specifications subject to
change without notice.
Reference
Power
Cool Valve
NETWORK
Heat Valve
Fan High
Fan Medium
Fan Low
888.273.7876
201.767.3400
CHV-RTS
To Cresnet
®
TOP
NETWORK
