- Page 1 CHV-TSTAT-FCU Heating and Cooling Fan-Coil Thermostat Supplemental Guide Crestron Electronics, Inc.
- Page 2 Other trademarks, registered trademarks, and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of others. Crestron is not responsible for errors in typography or photography.
- Page 3 Contents Introduction Set Up the Thermostat Enter Setup Mode ....................1 Navigate Setup Mode ..................... 1 Configure the Thermostat..................2 Supplemental Guide – DOC. 7963A Contents • i...
- Page 5 CHV-TSTAT-FCU needs to be set up. Refer to the ® information that follows for an overview of the setup procedure. For more information on the CHV-TSTAT-FCU, refer to the CHV-TSTAT-FCU DO Guide (Doc. 7914). Set Up the Thermostat A qualified technician should set up the thermostat locally. Navigate through the setup screens and make the changes necessary for the HVAC system.
-
Page 6: Configure The Thermostat
The Show Hum View Pg shows the humidity details when the VIEW button is pressed. Use the Cold Weather Comp option to adjust the thermostat to prevent condensation on the windows when the outdoor temperature is cold. 2 • CHV-TSTAT-FCU: Heating and Cooling Fan-Coil Thermostat Supplemental Guide – DOC. 7963A... - Page 7 Dual Setpoint Auto allows two set points to be established when operating in auto mode. When operating in Dual Setpoint Auto mode, while the temperature set points are flashing, press the MODE button to toggle between the two. Supplemental Guide – DOC. 7963A CHV-TSTAT-FCU: Heating and Cooling Fan-Coil Thermostat • 3...
- Page 8 SETUP: H-SENSORS Screen The SETUP: H-SENSORS screen allows the sensors values to be fine-tuned. SETUP: SENSOR DBG Screen Press VIEW to run sensor debugging. 4 • CHV-TSTAT-FCU: Heating and Cooling Fan-Coil Thermostat Supplemental Guide – DOC. 7963A...
- Page 9 The SETUP: SERVICE/TEST screen allows testing of the HVAC system directly from Setup mode. Set the Heat Call, Cool Call, Humidifier Call, or Fan Call to ON to test the HVAC system. Supplemental Guide – DOC. 7963A CHV-TSTAT-FCU: Heating and Cooling Fan-Coil Thermostat • 5...
- Page 10 Crestron Electronics, Inc. Supplemental Guide – DOC. 7963A 15 Volvo Drive Rockleigh, NJ 07647 (2048037) Tel: 888.CRESTRON 01.17 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
