Service Level; Picture - PDi -P15LCDC-ARM User Manual

Service Level

Service Level
The TV can be configured with 3 different banks of channels called Service Levels. Each
Service Level can be programmed with any combination of channels. For example, a
hospital usually elects to dedicate one of the service levels for Pediatrics and another for
Maternity since additional or banned channels may be found in either location that would
not be normally shown to the general patient population. A DISABLED service level is also
available that does not display any channels but rather a disabled message on the TV's
screen when the TV is turned on.
To change a Service Level.
1. Press the MENU button to display the
SETUP menu.
2. Press the CH▲ / CH▼ buttons to
highlight the Service Level item.
3. Press the VOL◄ / VOL► button to
select the desired service level.
4. Press the MENU button or TV/AV
button to exit.
NOTE: If a service level is selected that is empty and has not been
programmed with channels, a warning message will be displayed on the
TV stating "No Channels Available, Please Contact a TV Representative."
After 15 seconds the TV will shut itself off to conserve power. To
eliminate this message switch the TV to a Service Level that has been
programmed with channels.


Adjustment of picture Brightness, Contrast, Color, Tint, Color Temperature and Sharpness is
available to customize the levels you prefer using the on-screen menus. Alternately, PDI factory
preset picture modes can be selected using the remote control.
1. Press the MENU button to display the SETUP menu.
2. Select the Picture menu item.
3. Press the CH▲ / CH▼ buttons to highlight the desired picture item.
4. Adjust the picture item using the
5. Press the MENU button to store the picture values.
NOTE: A separate set of picture parameters are available for external devices such as
PC's (PC Analog Picture).
VOL◄ / VOL► buttons to the desired level.
26
Document Number: PD196-104 Rev 1
