Connections

PC Connection

The TV can also be used as a computer monitor.
1. Connect the computer's video cable to the PC-ANALOG IN D-SUB socket of the set.
2. Connect the computer's audio cable to the PC-AUDIO jack of the set.
3. Verify that PC-ANALOG is enabled in the "Source Setup" menu. Please see "Source
Setup" instructions elsewhere in this manual for details.
4. Press the TV/AV button repeatedly until PC-ANALOG appears in the lower right corner
of the screen indicating selection of PC-ANALOG input.
5. Switch on the computer. The computer's screen should appear on the set.
Resolution
The TV / Monitor supports display of multiple resolutions. If possible, use 1024 x 768 @ 60Hz
video mode to obtain the best image quality. If used under the other resolutions, some scaled
or processed pictures may appear on the screen.
PC
22
