Counterbalance the weight of the monitor

The ARMSTSCP1 features a one-touch height adjustment design that enables you to
easily raise or lower your monitor. To use the one-touch height adjustment feature, you
need to counterbalance the weight of your monitor.
• If the monitor doesn't stay in position when you move it or it's difficult to raise or
lower it, use the 5 mm hex key to turn the screw in the top of the column to the
right or the left. (figure 31)
figure 31
Column
Instruction manual
Adjustment screw
43
5 mm hex key
