HANDLING GUIDELINES

Adhere to the following handling guidelines when using the
EVAL-ADGM1004SDZ:

Always treat the ADGM1004
and observe normal handling precautions, including
working only on static dissipative surfaces, wearing wrist
straps, and using other electrostatic discharge (ESD)
control devices.

Take care when connecting signals. Hold the EVAL-
ADGM1004SDZ from the edges to avoid any damage to
the device under test (DUT).

Avoid connecting live signal sources to the EVAL-
ADGM1004SDZ. Ensure that outputs are switched off
(preferably grounded) before connecting to the DUT. Ensure
that all instrumentation shares a common chassis ground.
as a static sensitive device
Rev. 0 | Page 12 of 18
EVAL-ADGM1004SDZ

Avoid running measurement instruments such as digital
multimeters (DMMs) in autorange modes. Some
instruments generate large transient compliance voltages
when switching ranges.

Use the highest practical range (lowest resolution) setting
for resistance measurements to minimize compliance voltages.

