UG-1462

EVALUATION BOARD SOFTWARE FOR SPI INTERFACE

INSTALLING THE SOFTWARE

The EVAL-ADGM1004SDZ uses the Analog Devices
Control, Evaluation (ACE) software. The
desktop software application that allows the evaluation and
control of multiple evaluation systems.
The ACE software installer installs the necessary SDP drivers
and .NET Framework 4 by default. Install the
before connecting the SDP-B
Find the ACE software and access to full instructions on how to
install and use the software on the Analog Devices website at
www.analog.com/ace.
When the installation is finished, the
the EVAL-ADGM1004SDZ plugins appear.

INITIAL SETUP

To set up the EVAL-ADGM1004SDZ, take the following steps:
1. Change the position of the P1, P2, P3, and P4 links to SDI,
CS , SCLK, and SDO, respectively.
2. Change the MODE link position from PIN to SPI and keep
the EXTD_EN link position set to INT.
3. Connect the EVAL-ADGM1004SDZ to the
and connect the SDP-B board to the PC via the USB cable.
4. Power up the EVAL-ADGM1004SDZ as described in the
Power Supply section.
5. Run the ACE software. The EVAL-ADGM1004SDZ
plugins appear in the Attached Hardware section of the
Start tab (see Figure 2).
6. Double click the EVAL-ADGM1004SDZ plugin to open
the EVAL-ADGM1004SDZ view in Figure 3.
7. Double click the ADGM1004
diagram (see Figure 4). This diagram provides a basic
representation of the EVAL-ADGM1004SDZ functionality.
The main functions are labeled in Figure 4.
Figure 2. EVAL-ADGM1004SDZ Plugin Startup Window
Analysis,
ACE software is a
ACE software
board to the EVAL-ADGM1004SDZ.
ACE software starts and
SDP-B board,
chip to access the chip block
EVAL-ADGM1004SDZ
Table 5. SPI Interface Link Descriptions
Link Position
P1 SDI
P2 CSB
P3 SCLK
P4 SDO
Figure 3. Evaluation Board View of the EVAL-ADGM1004SDZ Plugin
Figure 4. Chip Block Diagram View of the EVAL-ADGM1004SDZ Plugin
Rev. 0 | Page 6 of 18
User Guide
Description
Serial data input (SDI) pin
Chip select (CS) pin
Clock input (SCLK) pin
Serial data output (SDO) pin
