Coltri Sub MCH 13/ET Compact Instruction Manual page 89

MCH 26-32/ET MCH 26-32/ET MCH 26-32/ET
MCH 26-32/ET MCH 26-32/ET
POS.
272
279
325
326
327
328
329
330
331
332
333
334
335
336
337
Spare parts
CODE DESCRIPTION
13-04-0272 CONDENSATION DISCHARGE CAN COMPLETE WITH PIPE FITTINGS
13-04-0279 VIBRATION DAMPNER WITH DOUBLE ATTACHMENT
13-04-0409 PUMP UNITS REAR PANEL
13-04-0410 COMPACT UPPER PANEL
13-04-0411 OIL REFILL CAP B
13-04-0412 OIL REFILL CAP A
13-04-0413 COMPACT STAY BOLT M6
13-04-0414 COMPACT LEFT-HAND SIDE PANEL
13-04-0415 LEFT INTERNAL CONVEYOR
13-04-0416 RIGHT INTERNAL CONVEYOR
13-04-0417 MOTOR-COMPRESSOR SUPPORT
13-04-0418 UPPER INTERNAL CONVEYOR
13-04-0419 COMPACT REAR PANEL
13-04-0420 COMPACT RIGHT-HAND SIDE PANEL
13-04-0421 BASE
89
