Pack contents
Pack contents
5.2
5.2
Pack contents
Pack contents
Pack contents
5.2
5.2
5.2
The standard equipment with which the machine is supplied is:
- 2 refill hoses measuring 1200 mm with valve for model MCH 13-16/ET Compact and 4 hoses for model
MCH 26-32/ET Compact;
- operating and maintenance booklet;
- enclosure with the Instruction Manual (Safety regulations);
- lubricating oil in cans (2 lt for model MCH 13-16/ET Compact and 4 lt for model MCH 26-32/ET
Compact).
5.3
5.3
5.3
Handling the machine
Handling the machine
Handling the machine
Handling the machine
Handling the machine
5.3
5.3
Having removed the compressor from its pack as described in the previous paragraph, the machine can
be moved to its place of installation.
27
28
To carry out this operation, it is necessary to use
a fork-lift truck or transpallet (of a suitable
capacity), the forks of which must be positioned
between the feet of the europallet on which the
machine is placed (Fig. 27).
Model MCH 26-32/ET is fitted with special side
members fixed under the structure (Fig. 28) that
enable the machine to be lifted with a fork-lift truck
even when it is not on a europallet.
26
Unpacking and handling the machine
