MCH 13-16/ET

MCH 13-16/ET
MCH 13-16/ET MCH 13-16/ET MCH 13-16/ET
POS.
208
209
210
210/A
211
217
221
222
224
230
231
232
233
234
235
250
251
252
253
254
255
256
257
258
272
276
279
300
301
301/A
302
307
308
309
310
311
312
Spare parts
CODE DESCRIPTION
13-04-0208 COMPLETE LOCK
13-04-0209 SWITCHBOARD PANEL
SC000310 280 BAR PRESSURE SWITCH
SC000315 330 BAR PRESSURE SWITCH
13-04-0211 PRESSURE GAUGE WITH FLANGE
13-04-0217 RELOAD RAMP ALUMINIUM BLOCK
13-04-0221 LP CONDENSATION DISCHARGE SOLENOID VALVE
13-04-0222 HP CONDENSATION DISCHARGE SOLENOID VALVE
13-04-0224 CONDENSATION DISCHARGE ALUMINIUM BLOCK
13-04-0230 OIL DISCHARGE COCK
13-04-0231 ¹/ " OIL DISCHARGE CAP
2
13-00-0164 CONDENSATE DISCHARGE HANDWHEEL
13-00-0163 CONDENSATE DISCHARGE SPRING
13-00-0162 NYLON CONDENSATE DISCHARGE
13-00-0161 CONDENSATE DISCHARGE TAP CASING
13-04-0400 COMPACT FRONT PANEL
13-04-0401 COMPACT LEFT-HAND SIDE PANEL
13-04-0402 COMPACT REAR PANEL
13-04-0403 COMPACT RIGHT-HAND SIDE PANEL
13-04-0404 COMPACT UPPER INSTRUMENT PANEL
13-04-0405 COMPACT UPPER PANEL
13-04-0406 MOTOR-COMPRESSOR SUPPORT
13-04-0407 BASE
13-04-0408 COMPACT OIL LEVEL PLATE
13-04-0272 CONDENSATION DISCHARGE CAN COMPLETE WITH PIPE FITTINGS
16-05-030 VIBRATION-DAMPING SUPPORT
13-04-0279 VIBRATION DAMPNER WITH DOUBLE ATTACHMENT
SC000450 BC INT COCK
SC000460 BC DIN 200 BAR COCK
SC000470 BC DIN 300 BAR COCK
13-04-238 HP 1200 mm. PIPE
13-04-0203 OFF PLATE
13-04-0204 ON PLATE
13-04-0205 MANUAL PURGE PLATE
13-04-0202 YELLOW CONDENSATION DISCHARGE BUTTON
13-04-0201 GREEN START BUTTON
13-04-0200 RED STOP BUTTON
87
