Monobloc - Coltri Sub MCH 13/ET Compact Instruction Manual

Monobloc

Monobloc Monobloc
Monobloc Monobloc
POS.
001
008
016
040
042
050
052
054
055
058
059
060
061
062
064
065
066
067
068
070
071
073
074
076
088
090
091
Spare parts
CODE DESCRIPTION
13-00-0001 MONOBLOC
13-01-0008 FIRST STAGE TIE ROD
13-03-0016 THIRD STAGE TIE ROD
13-02-0040 SECOND STAGE TIE ROD
13-00-0042 FLANGE ROLLER BEARING NU305
13-00-0050 FILTER SIDE FLANGE
13-00-0052 OIL DISCHARGE EXTENSION
13-00-0021 CORNER ¹/
8
13-00-0055 SEEGER RETAINING RING J 62
13-00-0018 8 mm. NUT
13-00-0009 8 mm. FLAT WASHER
13-00-0018 8 mm. NUT
13-00-0061 OIL FILLING PIPE O-RING
13-00-0062 FLANGE O-RING
13-00-0064 OIL LEVEL CONTROL PIPE
13-00-0065 OIL FILLING PIPE FITTING
13-00-0048 8x25 TCE SCREW
13-00-0067 6x35 TCE SCREW
13-00-0062 FLANGE O-RING
13-00-0070 BALL BEARING 6302
13-00-0071 FAN SIDE FLANGE
13-00-0073 OIL SPLASH GUARD 30-48-8
13-00-0074 FAN-HOLDING HUB
13-00-0076 OIL FILLING PIPE WITH UPPER FLANGE
13-00-0088 8 mm. THREADED ROD
13-00-0090 OIL FILLING CAP
13-00-0048 8x25 TCE SCREW
PIPE FITTING 8 mm. RILSAN
71
