Cooling pipes

Cooling pipes Cooling pipes
Cooling pipes Cooling pipes
POS.
023
036
074
075
077
079
080
081
082
083
084
085
086
087
089
133
134
135
136
137
138
139
140
141
142
186
197
Spare parts
CODE DESCRIPTION
13-03-0023 6 mm. COOLING PIPE
13-00-0036 8 mm. PIPE
13-00-0074 FAN-HOLDING HUB
13-00-0075 8x30 TCE SCREW
13-00-0077 COOLING FAN
13-00-0079 12 mm. FLAT WASHER
13-00-0080 12x35 TCE SCREW
13-00-0081 10x40 TCE SCREW
13-00-0082 FAN FLANGE
13-00-0083 GALVANIZED PIPE-HOLDING BRACKET
13-00-0084 6x15 TCE SCREW
13-00-0085 1st-2nd STAGE 10 mm. COOLING PIPE
13-00-0086 6 mm. NUT
13-00-0087 6x30 TCE SCREW
13-00-0089 10 mm. 2nd-3rd STAGE COOLING PIPE
13-00-0133 6 mm. PIPE-HOLDING BRACKET
13-00-0134 VIBRATION-DAMPING PIPE-HOLDING RUBBER WASHER
13-00-0135 SINGLE 6 mm. PIPE-HOLDING BRACKET
13-00-0136 DOUBLE 6 mm. PIPE-HOLDING BRACKET
13-00-0137 SELF-LOCKING 6MA NUT
13-00-0137 SELF-LOCKING 6MA NUT
13-00-0137 SELF-LOCKING 6MA NUT
13-00-0137 SELF-LOCKING 6MA NUT
13-00-0141 6x25 TCE SCREW
13-00-0141 6x25 TCE SCREW
13-00-0186 3-HOLE PIPE-HOLDING BRACKET
13-00-0197 2-HOLE PIPE-HOLDING BRACKET
79
