Pistons Rod Unit - Coltri Sub MCH 13/ET Compact Instruction Manual

Pistons rod unit

Pistons rod unit
Pistons rod unit Pistons rod unit Pistons rod unit
POS.
072
098
099
100
101
104
105
106
107
108
109
110
111
112
112/A
113
113/A
114
115
116
116/A
117
117/A
118
118/A
119
120
121
122
127
128
129
130
131
132
192
193
194
Spare parts
CODE DESCRIPTION
13-00-0072 SEEGER RETAINING RING A 30
13-00-0098 GOOSENECK
13-00-0099 KEY
13-00-0100 COUNTERWEIGHT
13-00-0101 8 mm. SELF-LOCKING NUT
13-00-0104 8x65 TCE SCREW
13-00-0105 THIRD STAGE CONNECTING ROD
13-00-0106 SPACER
13-01-0107 FIRST STAGE CONNECTING ROD
13-00-0106 SPACER
13-00-0105 SECOND STAGE CONNECTING ROD
13-00-0110 SEEGER RETAINING RING
13-02-0111 2nd STAGE PIN
13-02-0112 SECOND STAGE 36 mm. PISTON
16-02-0112 SECOND STAGE 38 mm. PISTON
13-02-0113 SET OF 2nd STAGE 36 mm. PISTON RINGS
16-02-0113 SET OF 2nd STAGE 38 mm. PISTON RINGS
13-00-0110 SEEGER RETAINING RING
13-00-0110 SEEGER RETAINING RING
13-01-0116 FIRST STAGE 88 mm. PIN
16-01-0116 FIRST STAGE 95 mm. PIN
13-01-0117 FIRST STAGE 88 mm. PISTON
16-01-0117 FIRST STAGE 95 mm. PISTON
13-01-0118 SET OF 1st STAGE 88 mm. PISTON RINGS
16-01-0118 SET OF 1st STAGE 95 mm. PISTON RINGS
13-00-0110 SEEGER RETAINING RING
13-03-0120 GUIDING SLIDING BLOCK
13-02-0111 3rd STAGE PIN
13-00-0110 SEEGER RETAINING RING
13-00-0110 SEEGER RETAINING RING
13-00-0128 ROLLER CAGE
13-00-0128 ROLLER CAGE
13-00-0128 ROLLER CAGE
13-00-0106 SPACER
13-00-0132 HARDENED RING
13-00-0192 ROLLER CAGE
13-00-0192 ROLLER CAGE
13-00-0192 ROLLER CAGE
73
