Coltri Sub MCH 13/ET Compact Instruction Manual page 75

Cylinders unit Cylinders unit Cylinders unit
Cylinders unit Cylinders unit
POS.
002
002/A
007
015
017
018
019
021
022
024
037
038
039
043
043/A
123
124
125
126
190
191
Spare parts
CODE DESCRIPTION
13-01-0002 FIRST STAGE 88 mm. CYLINDER
16-01-0002 FIRST STAGE 95 mm. CYLINDER
13-01-0007 FIRST STAGE CYLINDER O-RING
13-00-0015 THIRD STAGE CYLINDER O-RING
13-02-0017 THIRD STAGE GUIDING CYLINDER
13-00-0018 8 mm. BOLT
13-00-0019 LUBRICATION INDICATOR PIPE
13-00-0021 CORNER ¹/
8
13-00-0018 8 mm. NUT
13-00-0018 8 mm. NUT
13-02-0037 SECOND STAGE 60 mm. GUIDING CYLINDER
13-00-0015 GUIDING CYLINDER O-RING
13-00-0039 SECOND STAGE CYLINDER O-RING
13-02-0043 SECOND STAGE 36 mm. CYLINDER
16-02-0043 SECOND STAGE 38 mm. CYLINDER
13-03-0123 3rd STAGE VITON O-RING
13-03-0124 SET OF 3rd STAGE PISTON RINGS
13-03-0125 14 mm. THIRD STAGE CYLINDER
13-03-0126 14 mm. THIRD STAGE PISTON
13-03-0190 THIRD STAGE 60 mm GUIDING CYLINDER
13-00-0039 THIRD STAGE GUIDING CYLINDER O-RING
PIPE FITTING 8 mm. RILSAN
