Product Overview
15
NO.
15 Solar Connector 1
16 Solar Connector 2
17 Handle Bar (Pre-Installed)
18 Back Door Locks
19 Handle Bar (Installation Required)
z Please inspect the unit for any visible damage including cracks, dents, deformation, and other
visible abnormalities before installation.
z All connector contacts shall be dry, clean, and free of any dirt and corrosion.
z DO NOT touch the exposed electrolyte or powder if the batteries inside LYCAN are damaged.
z Please wear proper protective equipment and use insulated tools during installation and operation.
