Powering Appliances

z LYCAN can power appliances at temporary sites, in permanent off-grid homes, and during
emergencies with Power Strips, AC Load Centers, and Transfer Switches respectively. Please
refer to the corresponding instructions based on actual applications.
z Please fully charge LYCAN prior to first use.
Temporary Power Supply
Recommended Accessories
*Power Strip
(20A Current Rating)
Connect the Power Strips (not included) with corresponding current ratings to the 20A and 30A AC
Outlets of LYCAN. Plug appliances into the Power Strips.
Loosen the captive screws to
open the Viewing Window.
20A AC Output Circuit Breaker
STEP-4.2
Push the switch up to close the corresponding AC Output Circuit
Breaker.
*Power Strip
(30A Current Rating)
30A AC Output Circuit Breaker
AC OUTPUT 20A
AC OUTPUT 30A
AC INPUT
STEP-4.1
AC OUTPUT 20A
AC OUTPUT 30A
AC INPUT
STEP-4.3
