Product Overview - Renogy LYCAN 5000 Power Box Quick Manual

Product Overview

1
8
NO.
Solar Inverter Charger Display
1
(Including Indicators and Buttons)
2 Solar Input Circuit Breaker 1
3 Solar Input Circuit Breaker 2
4 Battery Circuit Breaker
5 Surge Protection Device
6 Front Door Locks
7 AC Inlet (20A)
2 3
9 10 11
Item
4 5 6
6 12
NO.
8 Viewing Window
9 Bluetooth Module
10 AC Output Circuit Breaker (20A)
11 AC Output Circuit Breaker (30A)
12 AC Input Circuit Breaker (20A)
13 AC Outlet (30A)
14 AC Outlet (20A)
7
13 14
Item
