Wiring Diagram - Renogy LYCAN 5000 Power Box Quick Manual

Wiring Diagram

20A AC Input
(Wall Outlet or Generator)
AC
DC Positive
DC Negative
AC Output (20A
Maximum)
Communication
z This Quick Guide contains important installation, operation, and maintenance instructions for
Lycan 5000 Power Box. Please read the guide carefully before using.
z Please refer to the full user manual of LYCAN on renogy.com for more detailed instructions.
z Illustrations in the Quick Guide are for reference only.
z For any questions, please visit renogy.com for help.
02
Solar Array 1
AC INPUT
20A
AC OUTPUT
20A
SOLAR INPUT 1
+
+
SOLAR INPUT 2
EXPANSION
AC OUTPUT
30A
COMMUNICATION
AC Output (30A
Maximum)
Solar Array 2
-
-
48V 50AH BATTERY
Renogy 48V 50Ah Smart
Lithium Iron Phosphate Battery
