Demolition Hammer
Model: XP-G50VA
HANDLING INSTRUCTIONS
Before using this demolition hammer, please carefully read though these HANDLING
INSTRUCTIONS. Ensure that you know how the machine works, and how it should be operated.
Maintain the machine in accordance with the instructions, and make certain that the machine
work correctly, please store this instriation and other enclosed documents with the machine
together.
Bj: 2013
Zhejiang Xinpu Industrial & Commercial Co., Ltd.
106, No. 330 National Road, Huajie Industrial Zone, Yongkang City, Zhejiang 321300, P. R. China

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XP-G50VA and is the answer not in the manual?

Questions and answers

Related Manuals for Xinpu XP-G50VA

Summary of Contents for Xinpu XP-G50VA

  • Page 1 Maintain the machine in accordance with the instructions, and make certain that the machine work correctly, please store this instriation and other enclosed documents with the machine together. Bj: 2013 Zhejiang Xinpu Industrial & Commercial Co., Ltd. 106, No. 330 National Road, Huajie Industrial Zone, Yongkang City, Zhejiang 321300, P. R. China...

  • Page 2: General Power Tool Safety Warnings

    list: General Power Tool Safety Warnings Special Warning for Electric hammer Safety instructions Applications Technical Data Accessories Name of the parts Prior to operation Assembly Operation Maintenance and Service Warranty Environment General Power Tool Safety Warnings WARNING ： Read all safety warnings and all instructions. Failure to follow all warnings and instructions may result in electric shock, fire and/or serious injury.
  • Page 3 f) If operating a power tools in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock. 3) Personal safety a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication.

  • Page 4: Safety Instructions

    Special Warning for Electric hammer • Wear ear protection. Exposure to noise can cause hearing loss. • Use auxiliary handle with the tool. Loss of control can cause personal injury. • Hold Power tool by insulated gripping surfaces, when performing an operation where the cutting accessory may contact hidden wiring or its own cord.

  • Page 5: Technical Data

    Check with your local Authority or retailer for recycling advice. Applications The power tool is intended for chiseling work in concrete, brick, masonry and asphalt as well as for driving in and compacting, when using the respective accessories. Technical Data Demolition Hammer XP-G50VA Rated Voltage 220V-240V Frequency 50Hz 1200W Rated input 2700～3700...

  • Page 6: Optional Accessories (Sold Separately)

    OPTIONAL ACCESSORIES (sold separately) 1. Tine Chisel: 18*350mm (SDS max ) 2. Flat Chisel : 18*350mm (SDS max ) 3. Big Flat Chisel : 18*400mm (SDS max ) 4. Goose Chisel :18*400mm (SDS max ) 5. Surface Roughing (Hammering) (1) Bushing Tool (2) Shank 6.

  • Page 7: Prior To Operation

    Prior to operation 1. Power source Ensure that the power source to be utilized conforms to the power requirements which specified on the name plate of the hammer. 2. Power switch Ensure that the power switch is in the position of OFF. If the plug is connected to power receptacle while the power switch is in ON position, the demolition hammer will start operation immediately, which can cause serious accident! 3.

  • Page 8: Operation

    5 minutes to warm up. Shock absorption Equipment 4 The XP-G50VA is equipped with an active vibration reduction system, which cuts vibration of that of the without Active Vibration Reduction. This may significantly reduce the exposure level over the total working period.

  • Page 9: Maintenance And Service

    Repair, modification and inspection of Xinpu Power Tools must be carried out by a Xinpu Authorized Service Center. This Parts List will be helpful it presented with the tool to the Xinpu Authorized Serivde Center when requesting repair or other maintenance.
