Demolition Hammer
Model: XP-G55VA
HANDLING INSTRUCTIONS
Before using this demolition hammer, please carefully read
though these HANDLING INSTRUCTIONS. Ensure that you know how the machine works, and
how it should be operated. Maintain the machine in accordance with the instructions, and make
certain that the machine work correctly, please store this instriation and other enclosed
documents with the machine together.
Bj: 2011
Zhejiang Xinpu Industrial & Commercial Co., Ltd.
106, No. 330 National Road, Huajie Industrial Zone, Yongkang City, Zhejiang 321300, P. R. China

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XP-G55VA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Xinpu XP-G55VA

Summary of Contents for Xinpu XP-G55VA

  • Page 1 Bj: 2011 Zhejiang Xinpu Industrial & Commercial Co., Ltd. 106, No. 330 National Road, Huajie Industrial Zone, Yongkang City, Zhejiang 321300, P. R. China...

  • Page 2: General Power Tool Safety Warnings

    list: General Power Tool Safety Warnings Special Warning for Electric hammer Safety instructions Intended Use Specifications Accessories Name of the parts Assembly Operation Maintenance and Service Warranty Environment General Power Tool Safety Warnings WARNING ： Read all safety warnings and all instructions. Failure to follow all warnings and instructions may result in electric shock, fire and/or serious injury.
  • Page 3 d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock. e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
  • Page 4 c) Disconnect the plug from the power source before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally. d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool.
  • Page 5 Do not use the power tool with a damaged cord. Do not touch the damaged cord and pill the plug from the outlet when the cord is damaged while working. Damaged cords increase the risk of an electric shock. Connect power tools that are used in the open via a Ground Fault Circuit Interrupter (GFCL).

  • Page 6: Safety Instructions

    2. Safety instructions In this operator's manual/or machine’s labels following symbols are used: Accordance with essential applicable safety of European directives Double insulation Denote risk of personal injury, loss of life or damage to the tool in case of nonobservance of the instruction in this manual.

  • Page 7: Intended Use

    Intended Use The power tool is intended for chiseling work in concrete, brick, masonry and asphalt as well as for driving in and compacting, when using the respective accessories. Technical Data Demolition Hammer XP-G55VA 220-240V~ Rated Voltage Frequency 50Hz Rated input...

  • Page 8: Standard Accessories

    Accessories Standard accessories Hexagon bar wrench 10mm 1 piece Amphibious screwdriver 1 piece One bottle of grease Bull point chisel(18×400mm) 1 piece flat chisel(18×400mm) 1 piece Carbon brush((6.5×17×26)mm) 1 couple OPTIONAL ACCESSORIES (sold separately) 1. Tine Chisel: 18*400mm (SDS max ) 2.

  • Page 9: Changing The Tool

    Name of the parts 1. Hammer rod protector 2. Protective lining 3. Move limited ring 4. Shock Absorption Jacket 5. Switch 6. Speed Adjuster Function Knob 7. Indicator 8. Side Handle 9. Function Knob Assembly Auxiliary Handle Operate your power tool only with the Side Handle8. The Side Handle 8 can be set to any position for a secure and low-fatigue working posture.

  • Page 10: Operation

    Operation Observe correct mains voltage! The voltage of the power source must agree with the voltage specified on the type plate of the power tool. Switch ON: Push to the top as arrow 1 direction; Push back to max. as arrow 2 direction(power source on), then push as arrow 1 direction to max.( lock switch).

  • Page 11: Maintenance And Service

    If the power tool should fail despite the care taken in manufacturing and testing procedures, repair should be carried out by an after-sales service center for XINPU power tools. In all correspondence and spare parts orders, please always include the 8-digit article number given on the type plate of the power tool.
