Demolition Hammer
Model: XP-G65BC
HANDLING INSTRUCTIONS
With active vibration reducing system
Before using this demolition hammer, please carefully read
though these HANDLING INSTRUCTIONS. Ensure that you know how the
machine works, and how it should be operated. Maintain the machine in accordance
with the instructions, and make certain that the machine work correctly, please store
this instriation and other enclosed documents with the machine togeth
Bj:2013

Advertisement

loading
Need help?

Need help?

Do you have a question about the XP-G65BC and is the answer not in the manual?

Questions and answers

Related Manuals for Xinpu XP-G65BC

Summary of Contents for Xinpu XP-G65BC

  • Page 1 Demolition Hammer Model: XP-G65BC HANDLING INSTRUCTIONS With active vibration reducing system Before using this demolition hammer, please carefully read though these HANDLING INSTRUCTIONS. Ensure that you know how the machine works, and how it should be operated. Maintain the machine in accordance...

  • Page 2: Table Of Contents

    Contents 1. Machine information 2. Safety instruction 3. Assembly 4. Operation 5. Maintenance 1. Machine information Technical specifications XP-G65BC Machine Type Voltage AC 220-240V Frequency 50Hz Input power 2000W Impact rate...
  • Page 3 Optional accessories (sold separately） Notice: Optional accessories (sold separately) are recommended only for XINPU tool for specified purpose in manual, any other brand accessories or attachments used may present risk of injury.
  • Page 4 5. Bush hammer heads + Shank Hexagon size28*410 length (Unit: mm) Tooth distance: 12mm Tooth high: 8mm Length*width: 60*60mm 6. Tamping plate + Shank Hexagon size28*394 length (Unit: mm) Length*width: 150*150mm 7. Big flat spade+ Shank Hexagon size28*296 length (Unit: mm) Length*width: 170*150mm 8.

  • Page 5: Safety Instruction

    2. Safety instructions In this operator's manual/or machine’s labels following symbols are used: Read the manual carefully Accordance with essential applicable safety of European directives Double insulation Denote risk of personal injury, loss of life or damage to the tool in case of nonobservance of the instruction in this manual.
  • Page 6 General Power Tool Safety Warnings WARNING ： Read all safety warnings and all instructions. Failure to follow all warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term “power tool” in the warnings refer to your mains operated (corded) power tool or battery operated (cordless) power tool.
  • Page 7 d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
  • Page 8 12、Any damage and abnormal happen, please stop to use immediately and disconnect it, ask authorized serve center to check and repair. 13. Parts replace: Only original XINPU's parts can be used to replace by authorized service center. 14. Right use accessories and parts: Don't use other parts and accessories which not mentioned in the manual otherwise may cause injuries! 15.

  • Page 9: Assembly

    3. Assembly Name of the parts Retainer Head cover Aluminum head Second handle Fan cover Encloser Switch Main handle Mounting tool bits Warning: before do it, make sure unplug the machine! (1) Pull out of the retainer "2", turning 180℃ clockwise or anticlockwise, insert the accessory shank portion"1"...

  • Page 10: Operation

    Accessory Retainer pull out and eurn+/-180 Remarking: When you removing the accessory, such as a bull point, a cutter etc.., follow above procedure in reverse order. 4. Operation Prior to operation 1. Power source Ensure that the power source to be utilized conforms to the power requirements which specified on the name plate of the hammer.

  • Page 11: Maintenance

    Operation 1. Pull the trigger switch after applying the tip of the bit to crushing position. In some cases, it's necessary to punch the tip of the bit against the crushing position forcibly in order to begin the striking stroke. This is not due to malfunction of the power tool. It means that the safe guard mechanism against no-load striking is working.
  • Page 12 图 7 图 8 1. Loosen the 4 screws between aluminum head and gear box by 6 mm HEX head wrench.(See Fig1) 2. Disassemble the aluminum head, cylinder and piston.(See Fig2) 3. Clean the inside of aluminum head, must be free of metal chip and granular dust (See Fig3) 4.
  • Page 13 Maintenance and inspection Before do any maintenance, ensure unplug the plug. 1. Inspecting the demolition hammer Use a dull accessory, such as bull point, cutter, etc., will cause motor malfunction and efficiency degraded. Replace with a new one when your accessory is abased. 2.
  • Page 14 In case of alternation of the machine, not agreed upon by us, this declareation will lose its validity. Machine Description: Demolition Hammer Machine Type: XP-G65BC Applicable EC Directive: EC Machinery Directive (2006/42/EC) EC Low Voltage Directive (2006/95/EC)
