Craftbot Flow / Flow Xl Printer Components - CraftBot FLOW GENERATION IDEX User Manual

1.1. Craftbot Flow /XL printer components
1. Filament guide tube
2. Touchscreen LCD display
3. Hotend
4. Build plate
5. Z axis rod
6. USB connector for flash drive
7. Extruder
8. Filament guide tube holder
9. Filament spool holder
10. Filament spool
11. ON / OFF switch
12. AC power cable
13. LAN connection
14. Reset button
The model displayed is the Craftbot Flow IDEX.
The difference between the two models is the frame height.
See Specifications for the different dimensions.
1
3
7
6
7
13
14
IDEX USER MANUAL
1
2
3
4
5
9 9
8 8
10 10
11
12
4
