Introduction

Overview of the MERLIN LEGEND
MAIL System
The MERLIN LEGEND® MAIL Voice Messaging System provides the same
features and functionality as the MERLIN MAIL® Voice Messaging System
Release 3.0. However, its integrated design houses both the station port and the
voice mail functionality in a single module that plugs into the MERLIN LEGEND
backplane.
This new module replaces the hardware previously required to provide the same
voice messaging service: an 012 module, separate MERLIN MAIL R3 system,
and remote maintenance device. Figure 1-1 shows the MERLIN LEGEND MAIL
module with a four-port expansion voice-port card.
System Compatibility
The MERLIN LEGEND MAIL system is compatible with all domestic and
international releases of the MERLIN LEGEND Communications System. The
MERLIN LEGEND MAIL system is not compatible with MERLIN II systems.
NOTE:
The MERLIN LEGEND system must have a 391A3 or newer power supply
module.
System Capacities
The MERLIN LEGEND MAIL system can provide two-port, four-port, or six-port
voice mail service with a message storage capacity of 21 hours. Two ports are
built into the base module of the MERLIN LEGEND MAIL system module.
