Changing the Far-End
Disconnect Setting and
Adding a 3 db Boost

Overview

This appendix provides the step-by-step instructions for changing the far-end
disconnect setting and adding a 3 db boost.
NOTE:
These settings should not have to be modified. These settings may only
need to be changed if the system is operating in countries other than the
United States and Canada.
Changing the Far-End Disconnect
Setting
NOTE:
This setting should not have to be modified. The far-end disconnect
setting may only need to be changed if the system is operating in
countries other than the United States and Canada.
Switch 1, which is located inside the MERLIN LEGEND MAIL base module,
specifies the far-end disconnect signal. If Switch 1 is set to OFF, the far-end
disconnect is set to reliable forward disconnect signal (that is, the CO sends a
reliable forward disconnect signal). If Switch 1 is set to ON, the far-end
disconnect is set to busy tone signal (that is, the CO sends busy tone to signal
far-end disconnect). By default, Switch 1 is set to OFF (that is, the MERLIN
LEGEND MAIL system is set to reliable forward disconnect signal).
