AT&T Lucent Technologies MERLIN LEGEND Installation And Upgrade page 6

Figures
1
Introduction
1-1. MERLIN LEGEND MAIL Module with a Four-Port
Expansion Voice-Port Card
1-2. Two-Port Voice-Port Expansion Card
1-3. Four-Port Voice-Port Expansion Card
3
Upgrading the MERLIN LEGEND MAIL
System
3-1. Sliding Voice-Port Card into Module
3-2. Removing Disk Drive Assembly
3-3. Disk Drive Assembly
F
Changing the Far-End Disconnect Setting
and Adding a 3 db Boost
F-1. Removing Disk Drive Assembly
F-2. Location of Switches for Far-End Disconnect
and 3 db Boost
1-1
1-3
1-5
1-6
3-1
3-3
3-4
3-5
F-1
F-2
F-3
iii
