CHAPTER 4: CONSOLE OVERLAY AND WORKOUT DESCRIPTION
4.1 CONSOLE DESCRIPTION - CONTINUED
The RXP has a fully integrated touch screen display. All information required for workouts is explained on screen. Exploration of
the interface is highly encouraged.
A) POWER BUTTON: Press to wake display/power on. Press and hold for 3 seconds to put display to sleep. Press and hold for
10 seconds to power off.
B) LANGUAGE SELECTION
C) CLOCK
D) MENU: Touch to access various functions before or during your workout.
E) WORKOUTS: Touch to access a variety of target training options or preset workouts, fitness tests and drag ratio.
F) SIGN IN: Touch to sign in using your XID (RXP-WF, RXP-WFRF).
G) CURRENT SCREEN: Displays what screen you are currently viewing.
H) FEEDBACK WINDOWS: Displays Time, SPM, Watts, Heart Rate (BPM), Distance or Calories. Feedback varies based on
current screen.
I) CHANGE SCREEN: Swipe display left or right to cycle between different run screen options. Or select a metric with an
orange triangle to go straight to a desired screen.
J) TARGET TRAINING SCREEN: Press to return to target training screen when a target training option has been set. Press the
target icon to set a specific training goal and activate the LED color wrap.
• PERSONAL INFO: Enter weight, age and gender to ensure caloric data and the power-to-weight ratio is more accurate.
• BATTERY: Battery level is shown at the bottom of the MENU screen. Rowing can wake/power the console on. If the RXP is
being used in the self-powered mode and the battery continues to deplete, please plug in the Rower RXP.
