Chapter 6: Service Mode; Using Service Mode - Matrix RXP Service Manual

CHAPTER 6: SERVICE MODE

6.1 USING SERVICE MODE

1) To enter Service Mode, hold the screen "MATRIX" for 5's, when the display will show the keyboard, press "ENTER, 2, 0, 0, 1, ENTER" on
the number keypad and Manager Mode will appear on the display.
2) Service Mode is divided into 10 tabs, located on the left side of the screen. They are General, Workout, Setup Defaults, Update, Network
Setup, Asset Management, Hardware, Statistics, Service and Experimental.
3) Choose a tab by touching the screen over the desired tab.
4) Each of the tabs has options that will appear once you have chosen that particular tab.
5) Press the " " to exit Manager Mode.
