Summary of Contents for Matrix CXV
-
Page 2: Important Precautions
• This equipment is not intended for use by persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given When using Matrix Cycles, basic precautions should always be followed, including the supervision or instruction concerning use of the equipment by a person responsible for following: Read all instructions before using this equipment. -
Page 3: Frame Serial Number
F 1 Hardware Kit NEED HELP? If you have questions or if there are any missing parts, contact Customer Tech Support. FRAME SERIAL NUMBER CONSOLE SERIAL NUMBER MODEL: CXV MATRIX VIRTUAL TRAINING CYCLE * Use the information above when calling for service. - Page 4 ENGLISH ASSEMBLY SADDLE HANDLEBARS HORIZONTAL SADDLE ADJUSTMENT LEVER PHONE HOLDER SADDLE HEIGHT CONSOLE ADJUSTMENT LEVER WATER BOTTLE HOLDER MAIN FRAME CRANK SERVICE PANEL PEDALS FLYWHEEL FRONT STABILIZER TUBE TRANSPORT HANDLE TRANSPORT WHEELS REAR STABILIZER TUBE LEVELERS...
- Page 5 ENGLISH ASSEMBLY Hardware Bolt (M6x55-20L) Hardware Bolt (M8x40L) Bolt (M12x25L) Flat Washer (M12) Bolt (M12x70L) Torque Value 78 Nm / 58 ft-lb. Hardware Bolt (M6x50L) Remove and save for step 4 LEFT PEDAL Torque Value 10 Nm / 7.4 ft-lb...
- Page 6 ENGLISH ASSEMBLY Hardware Screw (M5x12L) Hardware Bolt (M6x55-20L) Bolt (M8x40-20L) Metal plate Route wires using provided cable ties From step 3 From step 5 Torque Value 12 Nm / 8.8 ft-lb. Hardware Hardware Screw (M5x12L) Screw (M5x12L) Remove outside screws From step 5 and save for step 7 Loosen top 2 inside screws...
- Page 7 ENGLISH ASSEMBLY ASSEMBLY COMPLETE Hardware Screw (M5x12L)
-
Page 8: Console Operation
CONSOLE OPERATION CONSOLE DESCRIPTION The Matrix machine is inspected before it is packaged. Carefully unpack the unit and dispose of the box material. Note: There is a thin protective sheet of clear plastic on the overlay of the console that should be removed before use. -
Page 9: User Sign-In
ENGLISH CONSOLE OPERATION LOGIN SCREEN LOGIN SCREEN Touch the LOGIN button to sign-in with your XID. • Touch the GUEST button to workout anonymously. • Touch the REGISTER button to create a new XID. • For help or more information, touch •... - Page 10 ENGLISH CONSOLE OPERATION GO SCREEN HOME SCREEN PROGRAM SETUP HOME SCREEN Change WORKOUT STATISTICS displayed at the bottom of the screen Return to the home screen whenever you’re using an app Adjust VOLUME and pair a BLUETOOTH device and/or ANT+ device Increase or decrease the resistance level Use the keypad to set resistance level.
-
Page 11: Apps And Entertainment
ENGLISH CONSOLE OPERATION APPS AND ENTERTAINMENT Workouts and app availability vary by model and software configuration. For the most up-to-date information, please visit matrixfitness.com SIMPLE MY MEDIA SPOTIFY Workout stats are displayed in 3 Connect and control audio and video files Browse and listen to your favorite customizable windows. -
Page 12: Before You Begin
ENGLISH CONSOLE OPERATION BEFORE YOU BEGIN POWER ACCURACY LOCATION OF THE UNIT This bike displays power on the console. The power accuracy of this model has been Place the equipment on a level and stable surface away from direct sunlight. The tested using the test method of ISO 20957-5:2016 to ensure a power accuracy within intense UV light can cause discoloration of the plastics. -
Page 13: Moving The Equipment
ENGLISH BEFORE YOU BEGIN MOVING THE EQUIPMENT LEVELING THE EQUIPMENT Please use transport handle at base of frame It is extremely important that the levelers are correctly when moving equipment. adjusted for proper operation. Turn leveling foot clockwise to lower and counter-clockwise to raise unit. Do NOT try moving equipment by pushing Adjust each side as needed until the equipment is or pulling on the console as this may cause... -
Page 14: Saddle Adjustment
ENGLISH BEFORE YOU BEGIN HOW TO ADJUST THE INDOOR CYCLE The indoor cycle can be adjusted for maximum comfort and exercise effectiveness. The instructions below describe one approach to adjusting the indoor cycle to ensure optimal user comfort and ideal body positioning;... -
Page 15: Maintenance
Make sure that the indoor cycle is level and does not rock. DAILY repair of any kind is qualified to do so. MATRIX dealers will provide service • Turn off the bike by unplugging the power cord from the wall and maintenance training at our corporate facility upon request. -
Page 16: Product Information
* Ensure a minimum clearance width of 0.6 meters (24”) for access to and passage around • MATRIX equipment. Please note, 0.91 meters (36”) is the ADA recommended clearance width for individuals in wheelchairs. Connect the equipment into an outlet on a circuit different •... - Page 17 © 2021 Johnson Health Tech Rev 1.0 A...
