JUNCTION BOX INSTALLATION INSTRUCTIONS*

Check to see all parts are in
1
the box.
Attach the camera to the
4
junction box using the
machine screws.
Use the dry wall anchors and
2
machine screws to mount the
junction box and rubber
gasket to the wall.
Attach the camera housing
5
to the junction box using the
assembly screws.
Insert wires through the
3
wall and make the
appropriate connections.
