- Page 1 BZ-18GTX-Fiber HDMI over Optical Fiber Extender...
-
Page 2: Table Of Contents
7. Mission Statement………………………………………………..8 8. Warranty Information…………………………………………….9 1. Introduction The BZ-18GTX-Fiber can extend HDMI signal up to 4K Ultra HD over 3300 feet/1000 meters (Single-mode cable) or 1000 feet/300 meters (Multi-mode cable) to an HDMI compatible display. It also supports bi-directional infrared control and RS-232 signals transmission. -
Page 3: Features
2. Features HDMI 2.0b (18Gbps), HDCP 2.2 and DVI compliant Video resolutions up to 4K2K@50/60Hz (YUV444) Audio supports LPCM2/5.1/7.1 CH, Dolby Digital, DTS, Dolby True HD, DTS-HD Master Audio Long distance transmission up to 3300 feet/1000 meters over single-mode fiber cable and up to 1000 feet/300 meters over multi-mode fiber cable (50/125µm/OM3) ... -
Page 4: Operation Controls And Functions
discharge) Connections Inputs: 1x HDMI Type A [19-pin female] 1x IR In [3.5mm Stereo Mini-jack] Transmitter 1x RS-232 [3.81mm Phoenix connector] Outputs: 1x Optical Fiber Out [LC female] 1x IR Out [3.5mm Stereo Mini-jack] Inputs: 1x Optical Fiber In [LC female] 1x IR In [3.5mm Stereo Mini-jack] Receiver Outputs: 1x HDMI Type A [19-pin female]... - Page 5 Power LED: System power indicator. Optical LED: Optical link indicator, illuminates when transmitter and receiver establish optical link. HDMI LED: HDMI input signal indicator, illuminates when HDMI input has an active signal. DC 5V: Connect 5V/1A adaptor for power supply. Optical: Connect to receiver with a single or multi-mode fiber cable.
- Page 6 IR In: Connect to an IR receiver cable and put IR receiver header close to display device’s IR receiver window. IR Out: Connect to an IR emitter cable and put IR emitter header close to source device’s IR receiver window. RS-232: RS-232 commands will pass through this extender.
-
Page 7: Connection Diagram
6. Connection Diagram... -
Page 8: Mission Statement
We believe everyone deserves to see, hear, and feel the advancements made in today’s AV world without having to break the bank. BZB Gear is the solution for small to medium-sized applications requiring the latest professional products in AV. -
Page 9: Warranty Information
8. Warranty Information BZB Gear | Second Year Assurance BZB Gear wants to assure you peace of mind. We're so confident in the quality of our products that along with the manufacturer's one-year limited warranty, we are offering free second-year warranty coverage upon registration*! Taking advantage of this program is simple, just follow the steps below: 1.
