- Page 1 USB 2.0 Extender over Single Cat.X User Manual...
-
Page 2: Table Of Contents
However, like all electronic equipment, the BG-USB-MR80 should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. -
Page 3: Introduction
Cat.X cable. The extender consists of two units, a transmitter and a receiver. The transmitter connects to the PC and the receiver connects to the peripheral device, such as USB printers, cameras, Storage devices, Card-Readers, and more. BG-USB-MR80 offers the most convenient solution for long distance USB 2.0 transmission. -
Page 4: Specifications
SPECIFICATIONS Model Name BG-USB-MR80 Technical BG-USB-MR80-T BG-USB-MR80-R Role of usage Transmitter [TX] Receiver [RX] USB compliance USB 2.0 high speed compliant Bandwidth Up to 480 Mbit/s USB over UTP 264feet (80 meters) Up to transmission Signal Equalization 2-pin dip switch at TX & RX [1] Human body model —... -
Page 5: Panel Description
PANEL DESCRIPTION ► Transmitting unit BG-USB-MR80-T Front Panel Rear Panel USB: Connect to USB Host 2-Pin Dip Switch for Equalization Selection: Use the dip switch (please refer to below table) to adjust equalization level. The equalization level varies from EQ#1 (MAX or strongest) to EQ#3 (MIN or weakest) for respective transmission length... -
Page 6: Receiving Unit ► Bg-Usb-Mr80-R
Receiving unit ► BG-USB-MR80-R Front Panel Rear Panel USB: Connect to USB Device USB: Connect to USB Device 2-Pin Dip Switch for Equalization Selection Use the dip switch (please refer to below table) to adjust equalization level. The equalization level... -
Page 7: Connection Diagram
CONNECTION DIAGRAM... -
Page 8: Warranty
WARRANTY BZBGEAR wants to assure you peace of mind. We're so confident in the quality of our products that along with the manufacturer's one-year limited warranty, we are offering free second-year warranty coverage upon registration*. Taking advantage of this program is simple, just follow the steps below: 1. -
Page 9: Mission Statement
MISSION STATEMENT BZBGEAR manifests from the competitive nature of the audiovisual industry to innovate while keeping the customer in mind. AV solutions can cost a pretty penny, and new technology only adds to it. We believe everyone deserves to see, hear, and feel the advancements made in today’s AV world without having to break the bank.
