3
C15
Attach the Bottom Shelf (C21) to the Gas Bottle Holder (C15) using ST4.8x15 Screws
(D6x2pcs). Take care not to over tighten these screws which will damage the plastic gas
bottle holder.
4
Attach the leg assembly to the bottom shelf assembly using M6x15 Bolts (D1x4pcs).
C21
6
D6
D1
