Assembly and Operating Instructions for
Outback® Omega 100, Omega 200 and Omega 300 Gas Barbecues
Omega 100
Photographs are not to scale.
Specifications subject to change
without prior notice.
•
For outdoor use only.
•
Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
•
Warning: accessible parts may be very hot. Keep young children away.
•
Do not move the appliance during use.
•
Turn off the gas supply at the gas bottle after use.
•
Any modification of the appliance, misuse, or failure to follow the instructions
may be dangerous and will invalidate your warranty. This does not affect your
statutory rights.
•
WARNING
Retain these instructions for future reference.
•
Leak test annually, and whenever the gas bottle is removed or replaced. Check
the hose connections are tight and leak test each time you reconnect the gas
bottle.

FOR YOUR SAFETY

If you smell gas:
1.
Shut off gas to the appliance.
2.
Extinguish any open flame.
3.
Open barbecue lid or hood.
4.
If odour continues, discontinue use and
contact your local dealer.
Omega 200
FOR YOUR SAFETY
1.
Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
2.
A gas bottle not connected for use shall not be
stored in the vicinity of this or any other
appliance.
Omega 300
0359

Advertisement

loading
Need help?

Need help?

Do you have a question about the Omega 100 and is the answer not in the manual?

Questions and answers

Related Manuals for Outback Omega 100

Summary of Contents for Outback Omega 100

  • Page 1: For Your Safety

    Assembly and Operating Instructions for Outback® Omega 100, Omega 200 and Omega 300 Gas Barbecues Omega 100 Omega 200 Omega 300 Photographs are not to scale. Specifications subject to change 0359 without prior notice. • For outdoor use only. •...
  • Page 2 A. Parts List Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see the corresponding Hardware Reference Diagram for your barbecue model. OUTBACK® OMEGA RANGE CODE PART OMEGA 100 OMEGA 200...
  • Page 3 B1. Parts Diagram: Omega 100 Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see ‘Hardware Reference Diagram: Omega 100.’ Pre-assembled body unit includes the following individual parts: A11 A12 A13 A14...
  • Page 4 B2. Hardware Reference Diagram: Omega 100 Specifications subject to change without prior notice. D4, D9...
  • Page 5 C1. Parts Diagram: Omega 200 Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see ‘Hardware Reference Diagram: Omega 200.’ Pre-assembled body unit includes the following individual A5 A10 A11 A12 A13 A14...
  • Page 6 C2. Hardware Reference Diagram: Omega 200 Specifications subject to change without prior notice. D4, D9 D5, D9 D6, D9, D10, D11 D7, D9...
  • Page 7 D1. Parts Diagram: Omega 300 Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see ‘Hardware Reference Diagram: Omega 300.’ Pre-assembled body unit includes the following individual A5 A10 B1 A11 A12 A13 A14...
  • Page 8 D2. Hardware Reference Diagram: Omega 300 Specifications subject to change without prior notice. D4, D9 D5, D9 D6, D9, D10, D11 D7, D9...
  • Page 9 Whilst every care is taken in the manufacture of this product, care must be taken during assembly in case sharp edges are present. Omega 100 Omega 200 Omega 300 *NOTE: The Warming Rack is not supplied for Omega 100 and Omega 200 Omega 100 Omega 200 Omega 300 Omega 100 and Omega 200 Omega 300 Warning: Care must be taken to ensure hood does not fall open unexpectedly.
  • Page 10 Omega 100 Omega 200 Omega 300 Omega 100 and Omega 200 Omega 300 *NOTE: Take care to fix the legs with Velcro attached as shown in the illustration. Omega 100 Omega 200 Omega 300 Omega 100 and Omega 200 Omega 300...
  • Page 11 Omega 100 Omega 200 Omega 300 Omega 200, Omega 300 users skip this step and proceed directly to Step 7. Omega 100 Omega 200 Omega 300...
  • Page 12 Omega 100 Omega 200 Omega 300 Omega 100 users skip this step and proceed directly to Step 8. Omega 200 Omega 300 Omega 100 Omega 200 Omega 300...
  • Page 13 Omega 200 Omega 300 Omega 100 users skip this step and proceed directly to Step 13. Omega 200 users perform this step for both left and right side shelves. Note: The spacers and side shelf brackets go on the inside of the barbecue frame.

  • Page 14: Burner

    Omega 100 Omega 200 Omega 300 Omega 200 users skip this step and proceed directly to Step 13. D6 D10 D11 D9 Fit the side burner venturi tube over the gas valve outlet. This is a loose fit and not a gas tight seal.
  • Page 15 Omega 100 Omega 200 Omega 300 Insert grease cup into wire cup holder. Omega 100 Omega 200 Omega 300 *NOTE: The Warming Rack is not supplied for Omega 100 and Omega 200...
  • Page 16 Omega 100 Omega 200 Omega 300 *NOTE: The Warming Rack is not supplied for Omega 100 and Omega 200 Omega 100 Omega 200 Omega 300 *NOTE: The Warming Rack is not supplied for Omega 100 and Omega 200...
  • Page 17 Omega 100 Omega 200 Omega 300 ASSEMBLY IS NOW COMPLETE. PROCEED TO THE NEXT PAGE FOR INSTRUCTIONS ON OPERATION AND MAINTENANCE. IMPORTANT - LEAK TESTING BEFORE USE, FAILURE TO CHECK AND PERFORM THE LEAK TEST COULD CAUSE SERIOUS INJURY, AND DAMAGE THE BARBECUE.

  • Page 18: Hood

    to detect any gas leaking from joints and E. Important Information connections of the barbecue after assembly. Please read these instructions carefully Leak test annually, and whenever the gas bottle is removed or replaced. before assembly and use of your barbecue. Do not store flammable materials near this Retain these...

  • Page 19: Body

    To prevent foods from sticking to the cooking G. Installation surface, please use a long handled brush to apply a light coat of cooking or vegetable oil Selecting a Location before each barbecuing session. (Note: This barbecue is for outdoor use only and When cooking for the first time, paint colours should be placed in a well-ventilated area, and may change slightly as a result.

  • Page 20: Grease Cup

    • When the right burner is lit, turn the Close the hood to cook the food ‘indirectly’. Avoid lifting the hood unnecessarily as heat is remaining burners on from right to left. • Confirm that each burner is alight before lost every time the hood is opened.
  • Page 21 ‘off’ position. may result in damage to the barbecue. It may • Turn off the gas supply at the gas bottle. be necessary to dry the barbecue and the • inside of the cover. It is possible for mould to Keep everyone at a safe distance from the barbecue and wait until the fire has burnt grow on any fat remaining on parts of the...
  • Page 22 Excess fat and Gas Consumption: food debris can be removed from inside the Omega 100: 446g/hr body using a soft plastic or wooden scraper. It Omega 200: 446g/hr is not necessary to remove all the grease from...

  • Page 23: Troubleshooting

    Troubleshooting Problem Possible Cause Solution Burner will not light using LP gas bottle is empty Replace with full bottle the ignition system Faulty regulator Have regulator checked or replaced Obstructions in burner Clean burner Obstructions in gas jets or gas hose Clean jets and gas hose Electrode or ignition button wire is loose Reconnect wire...
  • Page 24 OUTBACK barbecues are warranted to the original purchaser against defects in materials and workmanship for a period of one (1) year from the date of purchase. OUTBACK will, within this period, supply replacements for defective parts free of charge provided that: ♦...
