11
B10
Insert the Main Electrode (B10) into the hole at the bottom of the barbecue body and
secure with the pre-assembled nut.
12
Feed the Burner (B2) into barbecue body. Ensure that the burner venturi tubes are over the
ends of the gas valves. They are a loose fit and not a gas tight seal. Secure the burner with
the ST4.0x10 Screws (D4x2pcs).
B2
10
View from underneath the body
×
D4
√
