High-Voltage Dc Power Supplies - H3C SecPath F1000-AI-X0 Installation Manual

Figure7-17 PSR150-D1 power supply
(1) Handle
PSR450-12D
The PSR450-12D power supply provides a maximum output power of 450 W.
Figure7-18 PSR450-12D power supply
(1) Latch
(3) Handle

High-voltage DC power supplies

CAUTION:
You can install high-voltage DC power supplies only on the F1000-AI-60, F1000-AI-70,
F1000-AI-80, and F1000-AI-90 firewalls.
PSR450-12AHD
The PSR450-12AHD power supply provides a maximum output power of 450 W.
1 2
(2) Power receptacle
1
4
3
(2) Status LED
(4) Power receptacle
