System Option 17
System Option 18
System Option 19
System Option 20
System Option 21
Programmable Re-sets
The following key applies to the table below:
= E
Entry / Exit
= I
Immediate
The zone types are factory set as follows.
1
Set A E
Set B e
Set C e
e
Set D
12.2

Entering Engineer Mode

Enter
Engineer mode will be displayed.
Whilst in Engineer mode, you are able to remove any covers without creating a tamper alarm.
12.3 Setting Volume Control (Extension speaker only)
This volume is controlled via the adjustable volume pot on the main processor board.
1. Remove lid.
2. Set volume pot to desired volume (Clockwise Decrease & Anti Clockwise Increase)
3. Replace cover.
In an alarm condition the volume control is overridden and the speakers will operate at full volume.
NOTE: Each RKP has its own volume control pot.
12.4 Resetting the Non Volatile Memory (NVM) to Factory Settings
The panel may be programmed as power up NVM reset or engineer code only NVM reset.
Engineer Power Up NVM Reset
If the panel is configured by the engineer to allow the reset of the NVM back to factory settings by powering up the
system with the NVM reset pins shorted together.
Locate the NVM reset pins on the PCB, using the link pin provided connect the two pins together. Power down the
system (mains and battery). Restore power and remove the link. The system is now back to factory default settings.
Three tones will be heard on power up and a further three beeps after 10 seconds.
Engineer Only NVM Reset
Enter the engineer mode. Use the link supplied to connect the NVM reset pins together and enter
key pad. The system is now back to factory default settings.
12.5

Setting the Panel when Mains Fails

Under normal operation the panel will indicate a fault condition if the AC supply is disconnected. It will still be possible to
Set and Unset the control panel during a mains fail and no further action is required.
Full functionality of the control panel is available during mains fail providing the system is battery backed.
Page 48
: Alarm Off
P.A. On
Fire On
Confirmed Alarm Off
: Abort Alarm On
Set / Unset Off
System Faults Off
: Alarm Off
P.A. On
Fire On
Confirmed Alarm Off
: Abort Alarm On
Set / Unset Off
System Faults Off
: All resets
No Reset omit
Global Tamper Volt Free Loop
Telephone line monitoring Enabled
: 1
Access = A
Zone Number
2 3 4
a I I
a I I
a I I
a I I
5 6 7
I I I
I I I
I I I
I I I
8
I
I
I
i
on the
