User Unset Reporting Codes; Maintenance And Priority Codes; Restoral Reporting Codes - Pyronix ATLAS 8 PLUS Installation Manual

11.11.16 User Unset reporting codes

Enter Enter 2 digits for seven reporting codes. To disable an event insert blanks for both digits.
To use hex codes, use the up key to select the character required and the
Reporting codes are automatically stored after the 16th key press or

11.11.17 Maintenance and Priority Codes

Enter Enter 2 digits for eight maintenance / priority codes. To disable an event insert blanks for both digits.
To use hex codes, use the up key to select the character required and the
Reporting codes are automatically stored after the 16th key press or

11.11.18 Restoral Reporting Codes

Enter Enter 2 digits for eight restoral reporting codes. To disable an event insert blanks for both digits.
To use hex codes, use the up key to select the character required and the
Reporting codes are automatically stored after the 16th key press or
Page 38
Example
Unset User 1
Unset User 2
Unset User 3
Unset User 4
Unset User 5
Unset User 6
Unset User 7/Keyswitch
Example
P.A. alarm entered at RKP
Fire alarm entered at RKP
Engineer mode entered
Bell fuse failure
Auxiliary fuse failure
Battery trouble
AC fail
Global Tamper
Example
User Code Restoral
Bell Timeout Restoral
Battery restoral
A.C. Restoral
Test Transmission
Line Fail Restoral
External stu
Line Fail Restoral Digi
Power-up Restoral
key to accept.
key to accept.
key to accept.
key to accept.
key to accept.
key to accept.
