11.11.31 Communicator Test

Enter press the following keys to toggle through the following communication outputs.
NOTE: If the reporting format option is set to BSIA fast format, the following event tests will be sent to the alarm
receiving centre as events.
- Alarm
- P.A.
- Fire
- Confirmed alarm
- Abort
- Open / Close
Press the key to exit.

11.11.32 Miscellaneous Reporting Codes

Enter Enter two digits for the two reporting codes.
Examples
11.11.33 System Option 11 Day Mode Send Options
Enter followed by
Display Alarm
ON
Alarm On
OFF
Alarm Off
Enter to accept.
11.11.34 System Option 12 Day Mode Send Options cont.
Enter followed by
Display Alarm
ON
Abort On
OFF
Abort Off
Enter to accept.
11.11.35 System Option 13 Set A Send Options
Enter followed by
Display Alarm
ON
Alarm On
OFF
Alarm Off
Enter to accept.
Rins163 Issue 9
On board comms line fail
Off board stu line fail
- . The RKP LED will toggle on and off as the numbered keys are pressed.
Tamper
P.A. On
P.A. Off
- . The RKP LED will toggle on and off as the numbered keys are pressed.
Tamper
Set / Unset On
Set / Unset Off
- . The RKP LED will toggle on and off as the numbered keys are pressed.
Tamper
P.A. On
P.A. Off
Key Press
P.A.
Fire On
Fire Off
Key Press
P.A.
System Fault On
System Fault Off
Key Press
P.A.
Fire On
Fire Off
Fire
Confirmed Alarm On
Confirmed Alarm Off
Fire
Spare
Spare
Fire
Confirmed Alarm On
Confirmed Alarm Off
