Maximum Controls MAX Ultra Arm Manual page 9

MAX SOLAR CONTROL BOX
Steel housing
2-layer protection
Gold zinc
Electrostatic
powder coating
Gold plated
automobile connectors
through the system
SOLAR MODE
Switch to enable
low power draw
for solar mode
Loop Rack
OPTIONAL
ON and OFF
Power Supply Switch
30A
FUSE
Solar Regulator
24V, 10A
(MORNING STAR)
MAX ACTUATOR CONTROL B
Solar Application Guide/W
Solar Panel
NOTE: Cover solar panel
from sunlight BEFORE wiring
to prevent a shock from
Wire solar panel terminals to occurring.
solar regulator input
3
Caution: polarity matters Connect
solar panel
to regulator
4
Connect batteries to regulator
Control Panel
Two 12V 18 AH
(AGM Rechargable Batteries)
UL Reset Button
Jog Switch
OPTIONAL
Solar Regulator
24V, 10A
(MORNING STAR)
NOTE: For more
24V Solar Panel
information about solar
Output: 36 V (Max) -
panel wiring, see your
Open Circuit
chosen panel's manual.
Solar Regulator Terminal
SOLAR BATTERY
+ - + -
POWE
SOLAR
Neg - Bl
LOAD
+ -
