AC CONTROL BOX

Steel housing
2- layer protection
Gold zinc
Electrostatic
powder coating
Gold plated
automobile connectors
throughout the system
The AC Control Box features rugged metal construction that is gold zinc plated and powder
coated. Each AC Control Box comes with an exterior UL reset button, a convenient jog
key switch for emergency access or egress, a 10 amp power supply with two 115 VAC
accessory outlets, two 7 amp batteries conveniently located behind the control panel, a
loop rack and much more. A lockable steel cover finishes off this slick design.
A convenient LCD display keeps you informed. Functional data and error messages are
visible when an accessory failure or function is present. This makes troubleshooting and
monitoring a breeze.
These many features can be explored in our downloadable installation manual available on
max.us.com
Loop Rack
Two plugin
Safety Loop
power outlets
Center Loop
Exit Loop
7 amp
Fuse
ON and OFF
Power Supply
Switch
Control Panel
Two 12V 7 AGM Batteries
UL Reset Button
Jog Open/Close
Key Switch for emergency
access to property
Selectable Switch
115V or 230V AC
