ASYMMETRIC SPEED CONTROL

90° Open

For asymmetric installations the two independent closing speeds can be

adjusted to achieve a smooth closing sync. Whichever gate closes first,

slow it down. This enables the installer to visually sync the closing cycle.

This feature is unique to Maximum Control's actuators.

90° Open

Opening one 90° and the other is 75°

with the independent closing speeds adjusted

the closing gate leaves can be synced

75° Open
