Winmate S Series Quick Start Manual

7~15” hmi freescale cortex a9 i.mx6 dual core 1 ghz (optional quad core)
Hide thumbs Also See for S Series:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
7~15" S-Series HMI
Freescale® Cortex® A9 i.MX6 Dual Core 1 GHz (Optional Quad Core)
Android 6.0
Model No. W07FA3S-PCO1-POE
W07FA3S-PCO1AC-POE
W10FA3S-PCH2AC-PoE
W10FA3S-PCH2-POE
W10FA3S-PCH2LB
R15FA3S-PCC3-PoE
Quick Start Guide
Document Version 1.1
Document Part No. 9152111I1138
Please read these instructions carefully before using this product, and save this manual for future use.

Advertisement

Table of Contents
loading

Related Manuals for Winmate S Series

Summary of Contents for Winmate S Series

  • Page 1 7~15” S-Series HMI Freescale® Cortex® A9 i.MX6 Dual Core 1 GHz (Optional Quad Core) Android 6.0 Model No. W07FA3S-PCO1-POE W07FA3S-PCO1AC-POE W10FA3S-PCH2AC-PoE W10FA3S-PCH2-POE W10FA3S-PCH2LB R15FA3S-PCC3-PoE Quick Start Guide Document Version 1.1 Document Part No. 9152111I1138 Please read these instructions carefully before using this product, and save this manual for future use.

  • Page 2: Table Of Contents

    7~15" S-Series HMI Quick Start Guide Contents PREFACE CHAPTER 1: INTRODUCTION 1.1 I NTRODUCTION 1.2 P RODUCT EATURES 1.3 U NPACKING 1.4 M ECHANICAL IMENSIONS 1.5 C ONNECTOR ESCRIPTION CHAPTER 2: GETTING STARTED 2.1 C ONNECTING THE OWER 2.2 C ONNECTOR ESCRIPTION CHAPTER 3: MOUNTING...

  • Page 3: Preface

    Preface Preface Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer. Trademark Acknowledgement Brand and product names are trademarks or registered trademarks of their respective owners.
  • Page 4 7~15" S-Series HMI Quick Start Guide Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory. Note: A note is used to emphasize helpful information Important:...
  • Page 5 Preface Safety Information Warning!/ Avertissement! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis.
  • Page 6 7~15" S-Series HMI Quick Start Guide *Let service personnel to check the equipment in case any of the following problems appear: o The power cord or plug is damaged. o Liquid has penetrated into the equipment. o The equipment has been exposed to moisture. o The equipment does not work well or you cannot get it to work according to the user manual.
  • Page 7 Preface Important Information Federal Communications Commission Radio Frequency Interface Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference.  This device must accept any interference received including ...

  • Page 8: Chapter 1: Introduction

    7~15" S-Series HMI Quick Start Guide Chapter 1: Introduction This chapter gives you product overview, describes features and hardware specification. You will find all accessories that come with the HMI in the packing list. Mechanical dimensions and drawings included in this chapter.

  • Page 9: Introduction

    1.1 Introduction Congratulations on purchasing Winmate® S-Series HMI. Interactive and smart automation systems of intelligent buildings are in a fast growing phase. Winmate® multi-touch S-Series HMI is suitable for home automation and room management systems. Flat surface is easy-to-clean and delivers aesthetically pleasing look for any interior. By connecting to centralized database, it can provide real time update for booking status and available schedule, or perform as a synchronous display in meetings.

  • Page 10: Unpacking

    7~15" S-Series HMI Quick Start Guide 1.3 Unpacking Carefully remove the box and unpack your HMI device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately.

  • Page 11: Mechanical Dimensions

    Chapter 1: Introduction 1.4 Mechanical Dimensions This section describes appearance, connectors’ layout and mechanical dimensions of S-Series HMI. Notice that this is a simplified drawing and some components are not marked in detail. Please contact our sales representative if you need further product information. 7-inch, W07FA3S-PCO1-POE/ W07FA3S-PCM1AC-PoE Unit: mm Dimensions:189.4 x 145.4 x 36.1...
  • Page 12 7~15" S-Series HMI Quick Start Guide 10.1-inch, W10FA3S-PCH2AC-PoE/ W10FA3S-PCH2-POE Unit: mm Dimensions:263.48 x 172 x 35.7 № № Description Description ① ⑥ Mini USB Console(Linux use) USB 2.0 x 1 ② ⑦ Micro SD Card Slot 12V DC ③ ⑧ LAN/ PoE* 2MP Front Camera (Optional) Status...
  • Page 13 Chapter 1: Introduction № № Description Description ① ⑦ Mini USB Console(Linux use) 12V DC ② ⑧ Micro SD Card Slot Micro HDMI ③ ⑨ LAN/ PoE* 12V DC (Phoenix type) ④ ⑩ USB OTG All-Around LED Status Light Bar ⑤...

  • Page 14: Connector Description

    7~15" S-Series HMI Quick Start Guide 1.5 Connector Description Terminal interfaces are located on the bottom side of the HMI device. Note: Notice that input and output connectors vary by product size and specifications. Terminal interfaces description: Item Description RJ45 – Connects HMI device to Ethernet network. Supports PoE for power transmission in network equipment, via network UTP cable, together with data.

  • Page 15: Chapter 2: Getting Started

    Chapter 2: Getting Started Chapter 2: Getting Started This chapter tells you important information on power supply, adapter and precautions tips. Pay attention to power considerations.

  • Page 16: Connecting The Power

    7~15" S-Series HMI Quick Start Guide 2.1 Connecting the Power Installation Instruction: Connect a 2-pin terminal block to the HMI connector. Connect the other side of the terminal block to the AC adapter. Connect the AC adapter to the power cord. Plug in the power cord to a working AC wall outlet.

  • Page 17: Connector Description

    Chapter 2: Getting Started 2.2 Connector Description 2.2.1 Power Input Connector The DC power source input of the S-Series HMI is a 2 pin terminal block connector that supports 9-24V DC or 12V DC power input depending on your model. Pin assignment and connector description of terminal block connector.
  • Page 18 7~15" S-Series HMI Quick Start Guide Pin assignment and connector description of USB connector. Pin № Pin№ Signal Name Signal Name USB_D- USB_D+ 2.2.5 USB OTG Connector Use USB OTG connector to connect the panel PC to other USB On-The-Go compliant devices such as flash drives, digital cameras, mice or keyboards.

  • Page 19: Chapter 3: Mounting

    Chapter 3: Mounting Chapter 3: Mounting This chapter provides mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages.

  • Page 20: Panel Mount

    7~15" S-Series HMI Quick Start Guide 3.1 Panel Mount Panel mount mounting solutions is suitable for many applications where HMI should be embedded in the machine. With this mounting solution flat surface leave no bezel in the front. Size Wall Cutout Screw Hole Diameter 7”...

  • Page 21: Vesa Mount

    Chapter 3: Mounting 3.2 VESA Mount 3.2.1 VESA Desk Stand PCVS-V1 The HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name PCVS-V1 Part No. 99KK00A0000E Installation Instruction Use provided Philips M4x5 screws to fix the desk stand to VESA holes on the back cover of the device.
  • Page 22 7~15" S-Series HMI Quick Start Guide 3.2.2 VESA Desk Stand LA-100 The HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name: LA-100 Part No. 9B0000000128 Installation Instruction Use provided Philips M4x5 screws to fix the desk stand to VESA holes on the back cover of the device.
  • Page 23 Chapter 3: Mounting 3.2.3 VESA Wall Mount Bracket LA-106 The HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name LA-106 Part No. 9B0000000412 Installation Instruction...
  • Page 24 7~15" S-Series HMI Quick Start Guide Accessories Dimensions...
  • Page 25 Chapter 3: Mounting 3.2.4 Front Side Wall Mounting You can purchase Front Side Wall Mount Bracket from Winmate as an optional accessory to 10.1” S-Series HMI. Model Name PCFW-V1 Part No. 99KK00A0000C Mounting Instruction 1. Cut a hole in the wall according to the cutout dimensions.
  • Page 26 7~15" S-Series HMI Quick Start Guide Dimensions...

  • Page 27: Chapter 4: Operating The Device

    Chapter 4: Operating the Device Chapter 4: Operating the Device In this chapter you will find instructions on how to operate the HMI device.

  • Page 28: Home Screen

    7~15" S-Series HMI Quick Start Guide 4.1 Home Screen Your device runs on Android 7.1 Operation System (Default). Navigation Buttons Back Opens the previous screen you were working in, even if it was in a different app. Once you back up to the Home screen, you can’t go back any further. Home Returns to the Home screen.

  • Page 29: Quick Settings

    Chapter 4: Operating the Device 4.2 Quick Settings You can open your device’s Settings app from the All Apps screen or from Quick Settings. For example, to change notification sounds, and volume go to Settings > Device > Sound to change the volume.

  • Page 30: Ethernet

    7~15" S-Series HMI Quick Start Guide 4.3 Ethernet 1. Connect Ethernet Cable to the HMI. 2. Touch All APPS icon, and the open Ethernet application. 3. Ethernet APP main menu appears...
  • Page 31 Chapter 4: Operating the Device 4.3.1 Configuring Ethernet Go to All Apps > Ethernet > Configure Ethernet *Ethernet OFF is set by default. Swipe Ethernet ON to activate Ethernet connection. Connection Type Setting Description DHCP The device automatically capture IP-address from the router Static IP Allows to manually set up IP-address, DNS, Network and Gateway 4.3.2 Checking Ethernet Settings...

  • Page 32: Winmate® Home Manager (Whm)

    7~15" S-Series HMI Quick Start Guide 4.4 Winmate® Home Manager (WHM) Winmate® S-Series HMI comes with preinstalled APP called Winmate® Home Manager (WHM) which let the device manager to lock the launcher then the user can only use one application assigned by the device manager.
  • Page 33 Chapter 4: Operating the Device 3. Go back to “Home Selector” and press “Clear and Reset Default Home”. 4. Select “Restrict Home” and “Always”, and then restart the computer to enable these settings.
  • Page 34 7~15" S-Series HMI Quick Start Guide The system will automatically start the application which you selected and lock it. Any time user presses home key or back key; the system will go back to the same application which you have selected.
  • Page 35 Chapter 4: Operating the Device Default password is “0000”. 3. Restart the system and you will go back to the normal Launcher. 4.4.3 How to Change Password To change the password: 1. Go to Password Manager and set your own password for this APP. 2.

  • Page 36: Configuring Serial Port Setting

    7~15" S-Series HMI Quick Start Guide 4.5 Configuring Serial Port Setting Serial port setting can be configured for RS-232, RS-422 or RS-485. Winmate provide serial port settings application for Android OS. To configure serial port settings: 1. Settings > Accessibility.
  • Page 37 Chapter 4: Operating the Device 3. Comport-Setting > Comport 1/ Comport 2/ Comport 3 * Select Comport 1/ Comport 2/ Comport 3 that you want to configure. 4. Comport 1 > RS232/RS422/RS485 * Configure Comport 1 settings...

  • Page 38: Appendix

    7~15" S-Series HMI Quick Start Guide Appendix Appendix A: Product Specifications Model Name W07FA3S- W07FA3S- W10FA3S- W10FA3S- W10FA3S- R15FA3S-PCC3- PCO1-POE PCO1AC-POE PCH2-POE PCH2AC-PoE PCH2LB Display 10.1" TFT 10.1" TFT Size/ Type 7" TFT (Wide) 7" TFT (Wide) 10.1" TFT (Wide) 15"...

  • Page 39: Appendix B: Hf Rfid Reader Specifications

    Appendix Model Name W10FA3S- W07RK3S- W07RK3S- W10RK3S- W10RK3S- R15RK3S- PCH2LB PCO1-POE PCO1AC-POE PCH2-POE PCH2AC-POE PCC3-POE Mechanical Specifications 189.4 x 145.4 189.4 x 145.4 263.28 x 171 x 263.28 x 171 x 263.28 x 171 x 363.40 x 277.86 Dimensions x 36.1 mm x 36.1 mm 35.7 mm 35.7 mm...
  • Page 40 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © Winmate Inc. All rights reserved.
