7"/ 10.4"/ 15"
S Series HMI
Intel® Celeron® Bay Trail-M N2930, 1.83 GHz
Model No. W07IB3S-PCO1-POE
W07IB3S-PCO1AC-POE
W10IB3S-PCH2-POE
W10IB3S-PCH2AC-POE
W10IB3S-PCH2LB
R15IB3S-PCC3-POE
Quick Start Guide
Document Version 1.3
Document Part No. 9152111I1140
Please read these instructions carefully before using this product, and save this manual for future use.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Winmate W10IB3S-PCH2LB
Summary of Contents for Winmate W10IB3S-PCH2LB
- Page 1 Intel® Celeron® Bay Trail-M N2930, 1.83 GHz Model No. W07IB3S-PCO1-POE W07IB3S-PCO1AC-POE W10IB3S-PCH2-POE W10IB3S-PCH2AC-POE W10IB3S-PCH2LB R15IB3S-PCC3-POE Quick Start Guide Document Version 1.3 Document Part No. 9152111I1140 Please read these instructions carefully before using this product, and save this manual for future use.
-
Page 2: Table Of Contents
7~15" S Series HMI Quick Start Guide Contents Preface ............................. 3 Chapter 1: Introduction ......................7 1.1 Introduction ......................8 1.2 Product Features ....................8 1.3 Package Contents ....................9 1.4 Mechanical Dimensions ..................10 1.5 Physical Buttons and LED Indicators ..............13 1.6 Connector Description .................. -
Page 3: Preface
Preface Preface Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer. Trademark Acknowledgement Brand and product names are trademarks or registered trademarks of their respective owners. - Page 4 7~15" S Series HMI Quick Start Guide Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings.
- Page 5 Preface Keep this equipment away from humidity. Put this equipment on a reliable surface during installation. Dropping it or letting it fall could cause damage. The openings on the enclosure are for air convection and to protect the equipment from overheating.
- Page 6 7~15" S Series HMI Quick Start Guide or a statement in the servicing instructions. These marking or statement shall include the following or similar text: Caution Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. Attention Risque d'explosion si la batterie est remplacée par un type incorrect.
-
Page 7: Chapter 1: Introduction
Chapter 1: Introduction Chapter 1: Introduction This chapter gives you product overview, describes features and hardware specification. You will find all accessories that come with the HMI in the packing list. Mechanical dimensions and drawings included in this chapter. -
Page 8: Introduction
7~15" S Series HMI Quick Start Guide 1.1 Introduction Congratulations on purchasing Winmate® S Series HMI. Winmate multi-touch S Series HMI is suitable for home automation and room management systems. Flat surface is easy-to-clean and delivers aesthetically pleasing look for any interior. The device provides real time update for booking status and available schedule, or performs as a synchronous display in meetings. -
Page 9: Package Contents
Chapter 1: Introduction 1.3 Package Contents Carefully remove the box and unpack your HMI device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Standard factory shipment list: ... -
Page 10: Mechanical Dimensions
7~15" S Series HMI Quick Start Guide 1.4 Mechanical Dimensions This section describes appearance, connectors’ layout and mechanical dimensions of S Series HMI. Notice that this is a simplified drawing and some components are not marked in detail. Please contact our sales representative if you need further product information. 7-inch, W07IB3S-PCO1-POE/ W07IB3S-PCO1AC-POE Unit: mm Dimensions:189.4 x 145.4 x 36.1... - Page 11 Chapter 1: Introduction 10.1-inch, W10IB3S-PCH2-POE/ W10IB3S-PCH2AC-POE Unit: mm Dimensions:263.48 x 172 x 35.7 № № Description Description ① ⑥ GPIO (Optional)* RJ-45 (LAN/ PoE)** ② ⑦ RJ-45 (LAN) 2MP Front Camera (Optional) ③ ⑧ USB 2.0, USB 3.0 HF RFID Reader (Optional) LED Status Light Bar ④...
- Page 12 7~15" S Series HMI Quick Start Guide 10.1-inch, W10IB3S-PCH2LB Unit: mm Dimensions:263.48 x 172 x 35.7 № № Description Description ① ⑤ RJ-45 (LAN) RJ-45 (LAN/ PoE)** ② ⑥ USB 2.0, USB 3.0 All-Around LED Status Light Bar ③ ⑦...
-
Page 13: Physical Buttons And Led Indicators
Chapter 1: Introduction 15-inch, R15IB3S-PCC3-POE Unit: mm Dimensions:363.4 x 277 x 86 x 44.5 № № Description Description ① ⑥ RJ-45 (LAN) Digital I/O (Optional) ② ⑦ USB 3.0 x 1 , USB 2.0 x 1 HF RFID Reader (Optional) ③... -
Page 14: Connector Description
7~15" S Series HMI Quick Start Guide Physical Buttons Icon Button Description Reset Press to reset the system Press to power on or power off the Power On/ Off device LED Indicators LED Type Status Description Power is on Power is off Storage activity Blinking (Data is being read or written) -
Page 15: Chapter 2: Getting Started
Chapter 2: Getting Started Chapter 2: Getting Started This chapter tells you important information on power supply, adapter and precautions tips. Pay attention to power considerations. -
Page 16: Powering On
7~15" S Series HMI Quick Start Guide 2.1 Powering On Installation Instruction: Connect a 3-pin terminal block to the HMI connector. Connect the other side of the terminal block to the AC adapter. Connect the AC adapter to the power cord. Plug in the power cord to a working AC wall outlet. - Page 17 Chapter 2: Getting Started 2.2.2 Ethernet Connector The HMI device has one RJ45 10/100/1000 Mbps Ethernet interface (LAN)for connecting to the internet and one RJ45 10/100/1000 Mbps Ethernet interface (LAN or PoE based on your order). Pin assignment and connector description of RJ45 connector. Pin №...
-
Page 18: Turning On And Off The Device
7~15" S Series HMI Quick Start Guide 2.2.5 GPIO Connector Notice that GPIO is an optional connector and may not be present in your model. Pin № Pin № Signal Name Signal Name 2.3 Turning On and Off the Device The unit is configured to Power ON when is connected to the power source. -
Page 19: Chapter 3: Mounting
Chapter 3: Mounting Chapter 3: Mounting This chapter provides mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages. -
Page 20: Panel Mount
7~15" S Series HMI Quick Start Guide 3.1 Panel Mount Panel mount mounting solutions is suitable for many applications where HMI should be embedded in the machine. With this mounting solution flat surface leave no bezel in the front. Size Wall Cutout Screw 7”... -
Page 21: Vesa Mount
Chapter 3: Mounting 3.2 VESA Mount 3.2.1 VESA Desk Stand PCVS-V1 The S Series HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name PCVS-V1 Part No. 99KK00A0000E Installation Instruction Use provided Philips M4x5 screws to fix the desk stand to VESA holes on the back cover of the device. - Page 22 7~15" S Series HMI Quick Start Guide 3.2.2 VESA Desk Stand LA-100 The S Series HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name: LA-100 Part No. 9B0000000128 Installation Instruction Use provided Philips M4x5 screws to fix the desk stand to VESA holes on the back cover of the device.
- Page 23 Chapter 3: Mounting 3.2.3 VESA Wall Mount Bracket LA-106 The S Series HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name LA-106 Part No. 9B0000000412 Installation Instruction...
- Page 24 7~15" S Series HMI Quick Start Guide Accessories Dimensions...
-
Page 25: Front Side Wall Mount
Chapter 3: Mounting 3.3 Front Side Wall Mount The Front Side Wall Mount is only available for 10.1” S Series HMI. You can purchase Front Side Wall Mount Bracket from Winmate. Model Name PCFW-V1 Part No. 99KK00A0000C Mounting Instruction 1. Cut a hole in the wall according to the cutout dimensions. -
Page 26: Glass Wall Mount
The Glass Wall Mounting is only available for 10.1” S Series HMI. The HMI device can be installed in a glass wall either from right side or from the left. You can purchase Winmate Glass Wall Mount Kit as an optional accessory. -
Page 27: Chapter 4: Operating The Device
Chapter 4: Operating the Device Chapter 4: Operating the Device In this chapter you will find instructions on how to operate the HMI device. -
Page 28: Hot Tab Menu
7~15" S Series HMI Quick Start Guide 4.1 Hot Tab Menu The S Series HMI has Hottab for quick control of main functions and system settings. To open Hottab: 1. Double-click the Hot Tab icon on the Windows desktop. 2. The Hot Tab main menu will appear on the screen as shown below. Note: RFID and LED Light Bar are optional features and may not be present in your model. - Page 29 Chapter 4: Operating the Device 4.1.3 Volume Tap Volume button to show your current volume level. To decrease the volume, drag by touch to the left. To increase the volume, drag by touch to the right. 4.1.4 LED Light Bar Notice that LED Light Bar is an optional feature for S Series HMI and may not be present in your device.
-
Page 30: Using Hf Rfid Reader
7~15" S Series HMI Quick Start Guide 4.1.6 Touch Lock To LOCK touch screen, double-click the Hot Tab icon on the Windows desktop, and tap Touch Lock. To UNLOCK the touch screen, tap button to the right. 4.2 Using HF RFID Reader Notice that HF RFID Reader is an optional feature for 10.1”... - Page 31 Chapter 4: Operating the Device To scan the card, bring it close to the right bottom front side of device with RFID icon. Tap on the Disconnect button to stop the connection with built-in HF RFID reader. 4.2.2 Trigger Setting ...
- Page 32 7~15" S Series HMI Quick Start Guide 4.2.3 Settings Sound: This setting defines whether a beep sound will come with the data scanning. Output: This setting defines the output type of the scanned data. Two options are available: ...
-
Page 33: Using Front Camera
Chapter 4: Operating the Device 4.2.4 RFID Output Settings Select RFID Output Type The default setting for built-in HF RFID Reader is to Read UID. For some applications, user might need to read or write further block data; the drop-down menu under this section can do this change. - Page 34 7~15" S Series HMI Quick Start Guide The Camera Screen Item Description Tap to record videos Video Tap to capture photos Photo Tap to select the destination folder to save captured photos and videos, enable preview, and select picture Settings resolution and quality.
- Page 35 Chapter 4: Operating the Device The preview screen automatically closes after 3 seconds. Alternatively, do one of the following: - Tap to delete the photo and return to the camera screen. - Tap to close the preview and return to the camera screen. 4.3.3 Recording Videos 1.
- Page 36 7~15" S Series HMI Quick Start Guide 4. Tap to stop recording and return to the camera screen. 5. To playback the video, browse for the video file and play using a media player application on your device. 4.3.4 Camera Settings 1.
-
Page 37: How To Enable Watchdog
Chapter 4: Operating the Device 4.4 How to Enable Watchdog To enable Watchdog, you need to download Winmate Watchdog utility. Find more information on Watchdog in “Watchdog Guide” that you can download from Winmate Download Center. To enable watchdog in Watchdog AP follow the instructions below: 1. -
Page 38: Appendix
7~15" S Series HMI Quick Start Guide Appendix Appendix A: Product Specifications Model Name W07IB3S- W07IB3S- W10IB3S- W10IB3S- W10IB3S- R15IB3S- PCO1-POE PCO1AC-POE PCH2-POE PCH2AC-POE PCH2LB PCC3-POE Display 10.1" TFT 10.1" TFT Size/ Type 7" TFT (Wide) 7" TFT (Wide) 10.1" TFT (Wide) 15"... -
Page 39: Appendix B: Hf Rfid Reader Specifications
Appendix Model Name W07IB3S- W07IB3S- W10IB3S- W10IB3S- W10IB3S- R15IB3S- PCO1-POE PCO1AC-POE PCH2-POE PCH2AC-POE PCH2LB PCC3-POE Input / Output Connectors 3-pin terminal 3-pin terminal 3-pin terminal 3-pin terminal 3-pin terminal 3-pin terminal Power block block block block block block 1 x RJ 45- 1 x RJ 45- 1 x RJ 45- 1 x RJ 45-... - Page 40 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © Winmate Inc. All rights reserved.
