S-Series Panel PC
AMD Geode LX 800 3.5" SBC, Ultra
Low Power, Fanless Design with
CPU, UXGA/LCD, Gigabit Ethernet
and Mini-PCI Interface.
USER'S MANUAL Version 1.3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Winmate S Series

Summary of Contents for Winmate S Series

  • Page 1 S-Series Panel PC AMD Geode LX 800 3.5” SBC, Ultra Low Power, Fanless Design with CPU, UXGA/LCD, Gigabit Ethernet and Mini-PCI Interface. USER’S MANUAL Version 1.3...
  • Page 2 AMD Geode LX Panel PC User’s Manual FCC Statement THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS： THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE. THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED PERATION.
  • Page 3 User’s Manual Copyright Notice Copyright © 2006 Winmate Technology Inc., ALL RIGHTS RESERVED. No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer.
  • Page 4 If any of these items are missing or damaged, contact your distributor or sales representative immediately. Winmate Customer Service Winmate provide service guide for any problem as follow steps：First, visit the Winmate website at http://www.winmate.com to find the update information about the product. Second, contact with your distributor, sales representative, or Winmate｀s customer service center for technical support if you need additional assistance.
  • Page 5 AMD Geode LX Panel PC User’s Manual Safety Precautions Warning! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges.
  • Page 6 AMD Geode LX Panel PC User’s Manual Safety and Warranty 1. Please read these safety instructions carefully. 2. Please keep this user's manual for later reference. 3. Please disconnect this equipment from any AC outlet before cleaning. Do not use liquid or spray detergents for cleaning.
  • Page 7 AMD Geode LX Panel PC User’s Manual Revision History Version Date Note Author 2006.05.01 First Version Wayne Lin 2006.09.20 Revise the Wayne Lin specification of Ethernet and Watchdog. For A830 ver.11 2006.10.31 Revise the Wayne Lin specification for A830 ver. 120 Update new BIOS setting for ver.

  • Page 8: Table Of Contents

    AMD Geode LX Panel PC User’s Manual Contents Chapter 1 General Information……….…… 1 1.1 Introduction……………………………… 1.2 System Specifications………………….. 1.3 LCD Specifications……………………… 4 1.4 Mechanical Drawing……………………. 1.5 Input / Output Devices………………….. 17 1.6 Mounting…………………………………. 18 Chapter 2 System Installation……………... 19 2.1 HDD Installation………………………… 2.2 Memory Module Installation……………...
  • Page 9 AMD Geode LX Panel PC User’s Manual Chapter 6 AUDIO Setup…………………….. 42 6.1 Introduction………………………………. 43 6.2 Installation of Audio Driver……………... 44 6.3 Further Information……………………… 46 Chapter 7 BIOS Setup………………………. 47 7.1 Starting Setup…………………………… 7.2 Award BIOS Setup……………………… 49 7.3 Standard CMOS Features Setup……… 51 7.4 Advanced BIOS Features Setup……….
  • Page 10 AMD Geode LX Panel PC User’s Manual Figures Figure 1.1 Product Overview……………………….. Figure 1.2 6.4 “ Mechanical Rear View Figure 1.3 6.4 “ Connector Description Figure 1.4 6.4 “ Mechanical Drawing Figure 1.5 6.5 “ Mechanical Rear View Figure 1.6 6.5 “ Connector Description Figure 1.7 6.5 “...
  • Page 11 AMD Geode LX Panel PC User’s Manual Figure 7.7 PC Health Status………………………… 62 Figure 7.8 Supervisor / User Password Setting…... 64 Figure 7.9 Save and exit setup screen…………….. 65 Figure 7.10 Exit without Saving setup screen………. 66...
  • Page 12 AMD Geode LX Panel PC User’s Manual Tables Table 1.1 LCD Specifications………………………. 4 Table 1.2 Input / Output Devices…………………... 17 Table 3.1 Jumpers…………………………………… 27 Table 3.2 Connectors……………………………….. Table 3.3 Clear CMOS (J5)………………………… Table 3.4 LVDS Voltage Select (JP10)……………. 31 Table 3.5 RS 232 / 422 / 485 Selector (JP13)……. 32 Table 3.6 RS 232 / 422 / 485 Selector (JP14)…….

  • Page 13: Chapter 1 General Information

    AMD Geode LX Panel PC User’s Manual General Information This chapter includes the PPC background information. Sections include: Introduction System Specification LCD Specification Mechanical Drawing Input / Output Devices Mounting...

  • Page 14: Introduction

    AMD Geode LX Panel PC User’s Manual 1.1 Introduction The Panel PC is high performance, fanless, low power PC with AMD CS 5536 chipset combine with a TFT LCD Panel. The AMD LX 800 fanless, high performance CPU delivers the most performance per watt available in the market.

  • Page 15: System Specifications

    AMD Geode LX Panel PC User’s Manual 1.2 System Specifications CPU: AMD Embedded LX-800 Micro-processor, Ultra-low power about 3.9Watts Chips set: AMD CS5536 Companion Device BIOS : AWARD Flash memory System memory: One 200-pin SODIMM socket accepts up to 1GB SDRAM Enhanced IDE interface : Supports up one channel two EIDE devices BIOS auto-detected for DMA33 mode(ATA-4)

  • Page 16: Lcd Specifications

    AMD Geode LX Panel PC User’s Manual 1.3 LCD Specifications Item Resolution Display Color Size (Recommended) R06A83S- 262144 640x480 XXP1 (6bit / colors) R06A83S- 640x480 260K XXM1 R08A83S- 262144 640x480 XXM1 (6bit / colors) R08A83S- 262144 800x600 XXU1 (6bit / colors) R08A83S- 262144 800x600...

  • Page 17: Mechanical Drawing

    AMD Geode LX Panel PC User’s Manual 1.4 Mechanical Drawing R06A83S-PMP1 Figure 1.2 6.4 “ Mechanical Rear View Figure 1.3 6.4 “ Connector Description...
  • Page 18 AMD Geode LX Panel PC User’s Manual Figure 1.2 Mechanical Drawing(8.4”For Example) Figure 1.4 6.4 “ Mechanical Drawing...

  • Page 19: Figure 1.5 6.5 " Mechanical Rear View

    AMD Geode LX Panel PC User’s Manual R06A83S-PMM1 Figure 1.5 6.5 “ Mechanical Rear View Figure 1.6 6.5 “ Connector Description...

  • Page 20: Figure 1.7 6.5 " Mechanical Drawing

    AMD Geode LX Panel PC User’s Manual Figure 1.7 6.5 “ Mechanical Drawing...

  • Page 21: Figure 1.8 8.4 " Mechanical Rear View

    AMD Geode LX Panel PC User’s Manual R08A83S-PMM1 / R08A83S-PMU1 / R08A83S-PMT1 Figure 1.8 8.4 “ Mechanical Rear View Figure 1.9 8.4 “ Connector Description...

  • Page 22: Figure 1.10 8.4 " Mechanical Drawing

    AMD Geode LX Panel PC User’s Manual Figure 1.10 8.4 “ Mechanical Drawing...

  • Page 23: Figure 1.11 10.4 " Mechanical Rear View

    AMD Geode LX Panel PC User’s Manual R10A83S-PMP1 / R10A83S-PMP3 / R10A83S-PMU1 / R10A83S-PMM1 / R10A830S-PMH1 Figure 1.11 10.4 “ Mechanical Rear View Figure 1.12 10.4 “ Connector Description...

  • Page 24: Figure 1.13 10.4 " Mechanical Drawing

    AMD Geode LX Panel PC User’s Manual Figure 1.13 10.4 “ Mechanical Drawing...

  • Page 25: Figure 1.14 12.1 " Mechanical Rear View

    AMD Geode LX Panel PC User’s Manual R12A83S-PML1 / R12A83S-PMM1 / R12A83S-PMM2 Figure 1.14 12.1 “ Mechanical Rear View Figure 1.15 12.1 “ Connector Description...

  • Page 26: Figure 1.16 12.1 " Mechanical Drawing

    AMD Geode LX Panel PC User’s Manual Figure 1.16 12.1 “ Mechanical Drawing...

  • Page 27: Figure 1.17 15" Mechanical Rear View

    AMD Geode LX Panel PC User’s Manual R15A83S-PMC3 / R15A83S-PMM4 / R15A83S-PMA1 Figure 1.17 15“ Mechanical Rear View Figure 1.18 15“ Connector Description...

  • Page 28: Figure 1.19 15" Mechanical Drawing

    AMD Geode LX Panel PC User’s Manual Figure 1.19 15“ Mechanical Drawing...

  • Page 29: Input / Output Devices

    AMD Geode LX Panel PC User’s Manual 1.5 Input / Output Devices The following figure shows the I/O arrangement of the Panel PC. The backside of the chassis contains most of the connectors. 9(option) 10(option) Figure 1.20 Input / Output Devices VR Control Use VR Control to adjust the PPC Display Brightness.

  • Page 30: Mounting

    AMD Geode LX Panel PC User’s Manual 1.6 Mounting The Panel PC is suitable for most of the industrial / commercial application, by any kind of mounting approach. Three main mounting approach, Panel Mount / Chassis / Open Frame, are very easy for user to install the Panel PC.

  • Page 31: Chapter 2 System Installation

    AMD Geode LX Panel PC User’s Manual System Installation This chapter includes hardware installation, DVD-Rom installation to the Panel PC. Sections include: HDD Installation Memory Module Installation I/O Equipment Installation Running the BIOS Setup Program...
  • Page 32 AMD Geode LX Panel PC User’s Manual Chapter 2 System Installation The PPC is a PC-based industrial computer that is housed in aluminum alloy front panel and heavy-duty steel chassis. And the following section will show the HDD and DVD-ROM installation process. Warning! The users must make sure to study all safety notifications before you begin the installation of the PPC.
  • Page 33 AMD Geode LX Panel PC User’s Manual 2.1 HDD Installation The PPC can have one Integrated Device Electronics （ IDE） connector for 2.5＂ or 3.5＂ HDD, the user can install HDD easily by removing the side cover of HDD drive bay. When installing the IDE HDD device, please follow the steps below：...
  • Page 34 AMD Geode LX Panel PC User’s Manual 2.2 Memory Module（SODIMM）Installation The Panel PC provides one 200-pin SODIMM slot. The socket supports up to 1GB DDR 400 SDRAM. When installing the Memory device, please follow the steps below： Step.1. Firmly insert the SODIMM at an angle into its slot. Align the SODIMM on the slot such that the notch on the SODIMM matches the break on the slot.

  • Page 35: I/O Equipment Installation

    AMD Geode LX Panel PC User’s Manual 2.3 I / O Equipment Installation 2.3.1 PS/2 Keyboard and PS/2 Mouse The PPC provides a Mini-DIN connector supports PS/2 interface. Mini-DIN connector supports Keyboard and Mouse through Y cable. Please plug keyboard or mouse directly with Y cable. In other cases, especially in embedded applications, a mouse is not used.

  • Page 36: Running The Bios Setup Program

    AMD Geode LX Panel PC User’s Manual 2.4 Running the BIOS Setup Program Panel PC is likely to have been properly set up and configured by your dealer prior to delivery. You may still find it necessary to change system configuration information by using the Panel PC’s BIOS (Basic Input-Output System) setup program, such as the date and time or your hard drive.

  • Page 37: Chapter 3 The Engine Of The Ppc

    AMD Geode LX Panel PC User’s Manual The Engine of the PPC Sections include: Introduction Features Jumpers and Connectors List Setting Jumpers and Connectors...
  • Page 38 AMD Geode LX Panel PC User’s Manual Chapter 3 The Engine of the PPC 3.1 Introduction The Panel PC is always a reliable SBC (Single Board Computer) based on the AMD LX 800 500MHz CPU. The PPC offers some built-in devices in a small 3.5”(146mm x 101mm) form factor., including network communications, a VGA / LCD controller, a SODIMM DDR socket.

  • Page 39: Table 3.1 Jumpers

    AMD Geode LX Panel PC User’s Manual 3.3 Jumper and Connector List It describes the locations of Jumpers and connectors. Be sure to read all the safety precautions before you begin the Jumper and Connector Setup. 3.3.1 Jumpers setting Please configure your card to match the needs of your application by setting jumpers.

  • Page 40: Table 3.2 Connectors

    AMD Geode LX Panel PC User’s Manual 3.3.3 Connectors List The table below lists the function of each of the board’s connectors. Label Function Note Cooling Fan connector 1 DF-13-3P-5V Inverter connector JST-B7B-PH-KL K/B Mouse connector 6-pin Mini Din TTL Connector DF13-40DP-1.25V VGA connector D-sub 15-pin ,female...
  • Page 41 AMD Geode LX Panel PC User’s Manual Figure 3-1 Locating Jumpers and Connectors on Panel PC (front side)
  • Page 42 AMD Geode LX Panel PC User’s Manual Figure 3-2 Locating Jumpers and Connectors on Panel PC (rear side)

  • Page 43: Clear Cmos

    AMD Geode LX Panel PC User’s Manual 3.4 Clear CMOS (J5) User must make sure the power supply to turn off the power supply before setting Clear CMOS. Users remember to setting jumper back to Normal before turning on the power supply. Clear CMOS Normal Functions...

  • Page 44: Rs 232 / Rs 422 / Rs 485 Selector

    AMD Geode LX Panel PC User’s Manual 3.6 RS 232 / RS 422 / RS 485 Selector (JP13&14) The jumper can be configured to operate in RS-232/422/485 mode. JP13 RS232 RS422 / 485 RS232 RS422/485 2-3 * 10-11 11-12 * Default value Table 3.5 RS 232 / 422 / 485 Selector (JP13) JP14 RS232...

  • Page 45: Chapter 4 Ethernet Interface

    AMD Geode LX Panel PC User’s Manual Ethernet Interface This chapter offers information on the Ethernet. Sections include: Introduction Installation of Ethernet Driver Further Information...

  • Page 46: Introduction

    AMD Geode LX Panel PC User’s Manual 4.1 Introduction The Panel PC is equipped with the Realtek RTL8110S-32 LOM Ethernet controller combines a triple-speed IEEE 802.3 compliant Media Access Controller (MAC) with a triple-speed Ethernet transceiver, 32-bit PCI bus controller, and embedded memory. With state-of-the-art DSP technology and mixed-mode signal technology, it offers high-speed transmission over CAT 5 UTP or CAT 3 UTP (10Mbps only) cable.
  • Page 47 AMD Geode LX Panel PC User’s Manual Setp.2. Click on “Next“ to install driver. Setp.3. Click “Finish” and restart the computer for new settings to take effect.

  • Page 48: Further Information

    AMD Geode LX Panel PC User’s Manual 4.3 Further Information The Realtek web site: http://www.realtek.com.tw Winmate web site: http://www.winmate.com.tw...

  • Page 49: Chapter 5 Vga Setup

    AMD Geode LX Panel PC User’s Manual VGA Setup This chapter offers information on the VGA. Sections include: Introduction Installation of VGA Further Information...

  • Page 50: Introduction

    AMD Geode LX Panel PC User’s Manual 5.1 Introduction offers an on-board PCI flat panel/VGA interface. The The Panel PC specifications and features are described as follows: The PPC supports . In addition, it also CRT and TFT LCD displays supports CRT and flat panel d simultaneously.
  • Page 51 AMD Geode LX Panel PC User’s Manual Step.2. Go to Driver page and choose “Update Driver” Step.3. Click Install from a list or specific location, and click on “Next”.
  • Page 52 AMD Geode LX Panel PC User’s Manual Step.4. Click on browse and select target folder, and click to ”Next”. Step.5. Click on “Continue Anyway” to go on. Step.6. Click “Finish” to finish the driver installation.

  • Page 53: Further Information

    AMD Geode LX Panel PC User’s Manual 5.3 Further information Winmate web site: http://www.winmate.com.tw...

  • Page 54: Chapter 6 Audio Setup

    AMD Geode LX Panel PC User’s Manual AUDIO Setup This chapter offers information on the VGA. Sections include: Introduction Installation of Audio Further Information...

  • Page 55: Introduction

    AMD Geode LX Panel PC User’s Manual 6.1 Introduction The Panel PC is equipped with the ALC203 is a 20-bit DAC and 18-bit ADC full-duplex AC'97 2.3 compatible stereo audio CODEC designed for PC multimedia systems, including host/soft audio, and AMR/CNR based designs. The ALC203 incorporates proprietary converter technology to achieve a high SNR (greater than 100 dB), sensing logics for device reporting, and a Universal Audio Jack®...

  • Page 56: Installation Of Audio Driver

    AMD Geode LX Panel PC User’s Manual 6.2 Installation of Audio Driver The users must make sure which operating system you are using in the Panel PC before installing the Audio drivers. Follow the steps below to complete the installation of the Realtek ALC203 AC97 Audio drivers. You will quickly complete the installation.
  • Page 57 AMD Geode LX Panel PC User’s Manual Step.3 Click Install from a list or specific location, and click on “Next”. Step.4 Click on browse and select target folder, and click to “Next”.

  • Page 58: Further Information

    AMD Geode LX Panel PC User’s Manual Step.5 Click on “Continue Anyway” to go on. Step.5 Click “Finish” to finish the driver installation. 6.3 Further Information The Realtek web site: http://www.realtek.com.tw Winmate web site: http://www.winmate.com.tw...
  • Page 59 AMD Geode LX Panel PC User’s Manual Award BIOS Setup This chapter describes how to set BIOS configuration.

  • Page 60: Starting Setup

    This is because the BIOS is revised and updated from time to time. If in doubt, check Winmate website for the latest BIOS versions and related information.

  • Page 61: Figure 7.1 Bios Setup Main Menu

    AMD Geode LX Panel PC User’s Manual 7.2 Award BIOS Setup Once you enter the Award BIOS™ CMOS Setup Utility, the Main Menu will appear on the screen. The Main Menu allows you to select from several setup functions and two exit choices. User the arrow keys to select among the items and press <Enter>...
  • Page 62 AMD Geode LX Panel PC User’s Manual Use this menu to install fail-safe defaults for all appropriate items in the setup utility. Load Optimized Defaults Use this menu to install optimized defaults for all appropriate items in the setup utility. Set Supervisor/User Password Use this menu to change, set, or disable supervisor/user password.

  • Page 63: Standard Cmos Features Setup

    AMD Geode LX Panel PC User’s Manual 7.3 Standard CMOS Features The Standard CMOS Features Setup allows users to configure system components such as date, time, hard disk drive, floppy drive and display. Use the arrow keys to highlight the item and then use the <Page Up> or <Page Down>...
  • Page 64 AMD Geode LX Panel PC User’s Manual Base Memory/Extended Memory/Total Memory These items are automatically detected by the system at start up time. These are display-only fields. You can not make change to these fields. Follow steps as IDE adapter below: IDE Adapters The IDE adapters control the hard disk drive.

  • Page 65: Advanced Bios Features Setup

    AMD Geode LX Panel PC User’s Manual 7.4 Advanced BIOS Features This section allows you to configure your system for basic operation. You have the opportunity to select the system’s default speed, boot-up sequence, keyboard operation, shadowing and security. Figure 7-3 Advanced BIOS Features Removable Device Priority You can choose the priority of your Removable Device The choice: LS120, USB-FDD0, USB-FDD1, USB-ZIP0,...
  • Page 66 AMD Geode LX Panel PC User’s Manual Quick Power On Self Test Enable this item to shorten the power on testing (POST) and have your system start up faster. You might like to this item after you are confident that your system hardware is operating smoothly.

  • Page 67: Advanced Chipset Features Setup

    AMD Geode LX Panel PC User’s Manual 7.5 Advanced Chipset Features These items define critical timing parameters of the mainboard. You should leave the items at their default values unless you are very familiar with the technical, specifications of your system hardware. If you change the values incorrectly, you may introduce fatal error or recurring instability into your system.
  • Page 68 AMD Geode LX Panel PC User’s Manual Output Display This item allows you select Output Display The choice: Flat Panel, CRT, or Panel & CRT. Flat Panel Type This item allows you select the resolution of the Display. Resolution 640 x 480 800 x 600* 1024 x 768 1280 x 1024...

  • Page 69: Integrated Peripherals

    AMD Geode LX Panel PC User’s Manual 7.6 Integrated Peripherals Figure 7-5 Integrated Peripherals On-Chip IDE Channel 1 The chipset contains a PCI IDE interface with support IDE channel. By default to activate the primary/secondary IDE interface. Master/Salve Drive PIO Mode The four IDE PIO (Programmed Input/Output) fields let you set a PIO mode (0-4) for each of the four IDE devices that the onboard IDE interface supports.

  • Page 70: Power Management Setup

    AMD Geode LX Panel PC User’s Manual 7.7 Power Management Setup The Power Management Setup allows you to configure your system to most effectively saving energy while operating in a manner consistent with your own style of computer use. Phoenix－AwardBIOS CMOS Setup Utility Power Management Setup Item Help ×...

  • Page 71: Pnp/Pci Configuration Setup

    AMD Geode LX Panel PC User’s Manual Power-On by Alarm When set to ‘Enabled’, the following three fields become available and you can set the date, hour, and minute to turn on your system. The choice: “Enabled” or “Disabled*”. * Default value Time (hh : mm : ss) of Alarm This item selects the alarm Time.
  • Page 72 AMD Geode LX Panel PC User’s Manual Shutdown Temperature This item allows you to select the shutdown temperature. The system will automatically shutdown while the CPU temperature has reach to the value you have set. The choice: 60C/140F, 65C/149F, 70C/158F, or Disabled. The following items provide you with information about the system’s current operating status.

  • Page 73: Load Fail-Safe Defaults

    AMD Geode LX Panel PC User’s Manual 7.10 Load Fail-Safe Defaults When you press <Enter> on this item, you will get confirmation dialog box with a message similar to: Load Fail-Safe Defaults (Y/N)? N Pressing ‘Y’ loads the BIOS default values for the most stable, minimal performance system operations.

  • Page 74: Supervisor / User Password Setting

    AMD Geode LX Panel PC User’s Manual 7.12 Supervisor / User Password Setting Figure 7-8 Supervisor / User Password Setting Steps to set supervisor/user password are described as follows: New password setting: While pressing <Enter> to set a password, a dialog box appears to ask you enter a password.

  • Page 75: Save And Exit Setup

    AMD Geode LX Panel PC User’s Manual 7.13 Save & Exit Setup Figure 7-9: Save and exit setup screen Pressing <Enter> on this item asks for confirmation: Save to CMOS and Exit (Y/N)? Y Press ‘Y’ stores the selections made in the menus of CMOS – a special section of memory that recorded in after you turn your system off.

  • Page 76: Chapter 8 Touch Screen

    AMD Geode LX Panel PC User’s Manual Touch Screen This chapter offers information on the Ethernet. Sections include: Introduction Installation of Drive for Elo AccuTouch TouchScreen Installation of Drive for Premier Touch TouchScreen...

  • Page 77: Introduction

    AMD Geode LX Panel PC User’s Manual Chapter 8 Touchscreen 8.1 Introduction The PPC supports two kinds of Touch Panel Solutions: Elo AccuTouch touchscreen or Premier Touch system. Both the two touchscreen system consists of a touchscreen and an electronic touchscreen controller. The Elo AccuTouch and Premier touchscreen is based on patented resistive technology.
  • Page 78 AMD Geode LX Panel PC User’s Manual 8.2.1 Configuration Utility After finishing the installation, please follow the steps to test the configuration utility. Step.1 Enter “My Computer”, click the “Elo touchscreen” shortcut function. Step.2 Click “Align” function key to go to next step.
  • Page 79 AMD Geode LX Panel PC User’s Manual Step.3 Correct 4 point locations on screen with the Panel PC. Screen display as follows. Step.4 Touch the “yes” function if the cursor follows your finger and finish the utility test.
  • Page 80 AMD Geode LX Panel PC User’s Manual 8.3 The Premier Touch Driver Installation TouchKit is the Premier Touch software, which contains drivers of the touch panel controllers for the specified communication connectors, RS232, PS/2 and USB, and the other two utilities. The two utilities are as follows: Touch Tray support This is utility for emulating the right and left button of mouse...
  • Page 81 AMD Geode LX Panel PC User’s Manual 8.3.1 Configuration Utility After finishing the installation, please follow the steps to test the configuration utility. Step.1 Click the “TouchKit” shortcut function in the desktop. Step.2 Enter “General” function and choose the language you need. Then go to next step.
  • Page 82 AMD Geode LX Panel PC User’s Manual Step.3 Correct 4 point locations on screen with the Panel. Screen display as follows Step.4 Play “Yes” to continue if 4 points calibration test is fine and finish the test.
  • Page 83 AMD Geode LX Panel PC User’s Manual Copyright Notice Copyright © 2006 Winmate Technology Inc., ALL RIGHTS RESERVED. No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer.

  • Page 84: Appendix A Pin Assignments

    AMD Geode LX Panel PC User’s Manual Pin Assignments...
  • Page 85 AMD Geode LX Panel PC User’s Manual A.1 Cooling Fan connector 1 (CN1) Pin# Function GND (black) FAN Voltage (red) Speed Signal from fan (yellow)
  • Page 86 AMD Geode LX Panel PC User’s Manual A.2 Inverter connector (CN2) Pin# Functions +12Volts +12Volts +12Volts Ground Brightness Control Ground On/Off...
  • Page 87 AMD Geode LX Panel PC User’s Manual A.3 K/B Mouse connector (CN3) Pin# Functions Mouse Clock KBD Clock Power +5Volts Ground Mouse Data KBD Data...
  • Page 88 AMD Geode LX Panel PC User’s Manual A.4 VGA Connector (CN5) Pin# Functions Red output Green output Blue output Ground Red Ground Green Ground Blue Ground N.C. Ground H Sync V Sync...
  • Page 89 AMD Geode LX Panel PC User’s Manual A.5 Mini PCI Socket (CN9)
  • Page 90 AMD Geode LX Panel PC User’s Manual A.6 Cooling Fan connector2 (CN10) Pin# Functions Fan Power 5Volts Fan Power Ground RPM output...
  • Page 91 AMD Geode LX Panel PC User’s Manual A.7 Brightness VR (JP9) Pin# Functions VR 1 VR Out VR 2...
  • Page 92 AMD Geode LX Panel PC User’s Manual A.8 RJ 45 Ethernet (CON1) Pin# Functions TX + TX - RX + RX - Signal Color Link Green Activity Orange...
  • Page 93 AMD Geode LX Panel PC User’s Manual A.9 DC Input Connector (J1)
  • Page 94 AMD Geode LX Panel PC User’s Manual A.10 SODIMM Connector (J7)
  • Page 95 AMD Geode LX Panel PC User’s Manual A.11 Serial port 1 connector (P1) Pin# Functions GOUND...
  • Page 96 AMD Geode LX Panel PC User’s Manual A.12 Serial port 2 connector (J10) Pin# Functions GOUND N.C.
  • Page 97 AMD Geode LX Panel PC User’s Manual A.13 Serial port 3 connector (J9) Pin# Functions GOUND POWER +5V...
  • Page 98 AMD Geode LX Panel PC User’s Manual A.14 Serial port 4 connector (J12) Pin# Functions GOUND POWER +5V...
  • Page 99 AMD Geode LX Panel PC User’s Manual A.15 USB Connector 1&2 (JUSB1&2) Pin# Signal USB VCC1 USB1- USB1+ Pin# Signal USB VCC2 USB2- USB2+...
  • Page 100 AMD Geode LX Panel PC User’s Manual A.16 USB Connector 3&4 (J11) Pin# Functions USB # 3 +5V Data3 - Data3 + USB # 3 Ground USB #4 Ground Data4 + Data4 - USB # 4 +5V...
  • Page 101 AMD Geode LX Panel PC User’s Manual A.17 Audio Connector (J14) Pin# Functions Line out R Line_in R input Mic. Input N.C. Line out L Line_in L input Mic.Vref N.C.
  • Page 102 AMD Geode LX Panel PC User’s Manual A.18 RTC BAT. Connector (J16) Pin# Functions Battery +3.0Volts...
  • Page 103 AMD Geode LX Panel PC User’s Manual...
