Winmate R15IB3S-PCC3-PoE Quick Start Manual

15 inch s-series hmi
Hide thumbs Also See for R15IB3S-PCC3-PoE:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
For more information on this and
other Winmate products, please
visit our website at:
www.winmate.com
Document Part Number: 9152111I100T
Please read these instructions carefully before using this product, and save this manual for future use
15" S-Series HMI
R15IB3S-PCC3-PoE
Quick Start Guide
V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R15IB3S-PCC3-PoE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Winmate R15IB3S-PCC3-PoE

Summary of Contents for Winmate R15IB3S-PCC3-PoE

  • Page 1 R15IB3S-PCC3-PoE Quick Start Guide V1.0 For more information on this and other Winmate products, please visit our website at: www.winmate.com Document Part Number: 9152111I100T Please read these instructions carefully before using this product, and save this manual for future use...

  • Page 2: Fcc Statement

    FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful  interference. This device must accept any interference  received including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class "B"...
  • Page 3 European Union Electromagnetic Compatibility Directive (2014/30/EU)  EN55024: 2010/ A1: 2015 o IEC61000-4-2: 2009 o IEC61000-4-3: 2006+A1: 2007+A2: 2010 o IEC61000-4-4: 2012 o IEC61000-4-5: 2014 o IEC61000-4-6: 2014 o IEC61000-4-8: 2010 o IEC61000-4-11: 2004  EN55032: 2012/AC:2013  EN61000-3-2:2014  EN61000-3-3:2013 Low Voltage Directive (2014/35/EU) ...

  • Page 4: Copyright Notice

    Brand and product names are trademarks or registered trademarks of their respective owners. Disclaimer Winmate Inc. reserve the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. We...
  • Page 5 Customer Service We provide a service guide for any problem by the following steps: First, visit the website of our distributor to find the update information about the product. Second, contact with your distributor, sales representative, or our customer service center for technical support if you need additional assistance.
  • Page 6 Safety Information WARNING! / AVERTISSEMENT! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis.

  • Page 7: Table Of Contents

    - 23 - Wiring Requirements - 23 - Mounting - 24 - SPECIFICATIONS - 30 - APPENDIX - 33 - Appendix A: Cleaning the Monitor - 33 - Appendix B: Winmate Software Development Kit - 34 - - 7 -...

  • Page 8: Introduction

    Congratulations on purchasing Winmate® 15” S-Series HMI. Interactive and smart automation systems of intelligent buildings are in a fast growing phase. Winmate® multi-touch S-Series HMI is suitable for home automation and room management systems. Flat surface is easy-to-clean and delivers aesthetically pleasing look for any interior.

  • Page 9: Package Contents

    Package Contents Carefully remove the box and unpack your device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Standard factory shipment list: Quick Start Guide Driver CD &...
  • Page 10 Package may include optional accessories based on your order: Front Side VESA Wall Mount VESA Desk Stand Wall Mount Kit Bracket LA-100 LA-106 PCFW-V2 9B0000000128 9B0000000412 99K000A00006. - 10 -...

  • Page 11: Product Overview

    Product Overview Unit: mm № Description № Description ① RJ-45 (LAN) ⑥ Digital I/O (Optional) HF RFID Reader ② USB 3.0 x 1 , USB 2.0 x 1 ⑦ (Optional) LED Status Light Bar ③ RS232/422/485 ⑧ (Optional) ④ 12V DC Terminal Block ⑨...

  • Page 12: Getting Started

    GETTING STARTED Turning On Your Device Follow the following steps to turn on your device: 1. Connect HMI device to a thermal block (3-pin). 2. Connect the other side of the thermal block to the AC adapter. 3. Connect the AC adapter to the power cord. 4.

  • Page 13: Connecting To Other Devices

    Connecting to Other Devices This section explains how to connect external interfaces to the HMI device. Power Connector DC power source input is a 3 pin terminal block connector. Minimum Voltage 11.4V Maximum Voltage 12.6V Maximum Current 4.2A Voltage Serial Port Connector Use COM1 serial port connector to connect your HMI to external devices such as mouse, modem or printer.
  • Page 14 RJ45 Connector The 15” S-Series HMI has two RJ45 connectors that support 10/100/1000 Mbps Ethernet interface for connecting to the internet. Notice that only one RJ45 connector supports PoE function. Pin № Signal Name Pin № Signal Name TX1+ TX1- TX2+ TX2- TX3+...
  • Page 15 Digital I/O Connector Notice that Digital I/O is an optional connector and may not be present in your model. Pin № Pin № Signal Name Signal Name - 15 -...
  • Page 16 Using HF RFID Reader Notice that HF RFID Reader is an optional feature for 10.1” S-Series HMI and may not be present in your device. HF RFID is commonly used for ticketing, payment, and data transfer applications. The RFID Reader is located on the bottom right front side of the HMI device.
  • Page 17 Reader Demo Version 1.04 Reading Mode Select the default RFID Reader COM14or press Search on the upper left corner of the screen. The system will automatically find RFID COM port, show the Version. Item № Key button Function E1- Version Displays the current version of RFID Reader system E2- Reset...
  • Page 18 UID0 Menu The system will read the data once the card will be near. You can select different reader modes. Each mode is described below. Item № Key button Function A0- Continuous The RFID Reader will perform a Read (default) series of multiple scanning operations A1- Once Read...
  • Page 19 Writing Mode Refer to the RFID Porting Guide SDK to configure Write Mode parameters. - 19 -...

  • Page 20: How To Enable Watchdog

    To enable Watchdog, you need to download Winmate Watchdog utility. Find more information on Watchdog in “Watchdog Guide” that you can download from Winmate Download Center or File Share. Refer to the User Manual for more details. To enable watchdog in Watchdog AP follow the instructions below: 1.
  • Page 21 Example: Every 10 min watchdog will monitor the system, in case any error occurs the system will restart automatically when the countdown time reaches 0. Every 9 min watchdog timer will be reset to 10 min. Settings Description The system automaticity restarts when Watchdog Countdown this countdown time reaches zero.

  • Page 22: Turning Off Your Device

    Turning Off Your Device To shut down your device, do the following: Tap Start ( ) > Shut down. Wait for your Panel PC to completely turn off before disconnecting the power cord (if necessary). - 22 -...

  • Page 23: Installation

    INSTALLATION Wiring Requirements The following common safety precautions should be observed before installing any electronic device:  Strive to use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must cross make sure the wires are perpendicular at the intersection point.

  • Page 24: Mounting

    Mounting S-series HMI devices come with different mounting options suitable for most of the industrial and commercial applications. S-series HMI devices come with different mounting options suitable for most of the industrial and commercial applications. Panel Mounting Wall cutout Screw hole diameter 360 x 292 mm M3x5 mm Mounting Instruction:...
  • Page 25 VESA Mounting VESA Desk Stand LA-100 The HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Mounting Instruction  Use provided Philips M4x5 screws to fix the desk stand to VESA holes on the back cover of the device.
  • Page 26 VESA Wall Mount Bracket LA-106 The HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name: LA-106 Part Number: 9B0000000412 Mounting Instruction Accessories - 26 -...
  • Page 27 Dimensions - 27 -...
  • Page 28 Front Side Wall Mounting You can purchase Front Side Wall Mount Bracket from Winmate as an optional accessory for 15” S-Series HMI. Model Name:PCFW-V2 Part Number:99K000A00006. Dimensions - 28 -...
  • Page 29 Mounting Instruction 1. Attach one part of the mounting bracket to the device; fix the bezel with Philips M4x5 screws. 2. Insert the iron box into the wall and fasten Philips M4x5 screws to fix the iron box to the fixture. 3.

  • Page 30: Specifications

    SPECIFICATIONS HMI Device Specifications Model Name R15IB3S-PCC3-PoE Size 15" TFT (Widescreen) Resolution 1024 x 768 Brightness 250 nits Display Max Colors 262K (6 bit) Projected Capacitive Multi- Touch Touch (P-CAP) Intel ® Celeron ® Bay Trail-M N2930 1.83GHz System Intel® ATOM SoC Integrated...
  • Page 31 1 x RJ 45-10/100/1000 Mbps (LAN) Ethernet Port 1 x RJ 45-10/100/1000 Mbps (LAN/ PoE) Digital /O Terminal Block 10- Digital I/O pin (Optional) Audio Output 1 Watt Speaker x 2 LED Status Built-in RGB LED Light Bar Peripheral Light Bar (Optional) RFID Reader HF RFID Reader (Optional)
  • Page 32 HF RFID Reader The RFID Reader can read and write data according to different HF RFID standards. HF RFID Purpose Standard Standard for MIFARE technology, which used in ISO-14443 A smart cards and proximity cards ISO-15693 Standard for tracking items Standard for Near Field Communication (NFC), ISO-18092 a short range technology that is commonly used...

  • Page 33: Appendix

    APPENDIX Appendix A: Cleaning the Monitor Before cleaning:  Make sure the device is turned off.  Disconnect the power cable from any AC outlet. When cleaning:  Never spray or pour any liquid directly on the screen or case. ...

  • Page 34: Appendix B: Winmate Software Development Kit

    Appendix B: Winmate Software Development Kit Winmate® provides Software Development Kit (SDK). The table below lists SDK provided by Winmate for 15” S-Series HMI with Intel ® Celeron ® Bay Trail-M N2930 processor: Item File Type Description Digital I/O SDK...
  • Page 35 NOTES _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________...
  • Page 36 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: www.winmate.com...
