S Series HMI
7"/ 10.1"/ 15"
Intel® Pentium® N4200 Processor (2M Cache, up to 2.5 GHz)
Model No. W07IP3S-PCO1AC-POE
W07IP3S-PCO1-POE
W10IP3S-PCH2AC-POE
W10IP3S-PCH2-POE
R15IP3S-PCC3-POE
User Manual
Document Version 1.1
Document Part No. 9171111I104F
Please read these instructions carefully before using this product, and save this manual for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Winmate S Series

Summary of Contents for Winmate S Series

  • Page 1 S Series HMI 7”/ 10.1”/ 15” Intel® Pentium® N4200 Processor (2M Cache, up to 2.5 GHz) Model No. W07IP3S-PCO1AC-POE W07IP3S-PCO1-POE W10IP3S-PCH2AC-POE W10IP3S-PCH2-POE R15IP3S-PCC3-POE User Manual Document Version 1.1 Document Part No. 9171111I104F Please read these instructions carefully before using this product, and save this manual for future use.

  • Page 2: Table Of Contents

    7”/ 10.1”/ 15” S Series HMI User Manual Contents Preface ............................. 5 About This User Manual ......................9 Chapter 1: Introduction ......................10 1.1 Introduction ......................11 1.2 Product Features ....................11 1.3 Package Contents ....................11 1.4 Mechanical Dimensions ..................12 1.5 Physical Buttons ....................
  • Page 3 Preface 4.2.3 Brightness ....................35 4.2.4 Volume ..................... 36 4.2.5 LED Light Bar ................... 36 4.2.6 Performance ..................... 37 4.2.7 Touch Lock ....................37 4.3 Using HF RFID Reader ..................37 4.3.1 HF RFID Reader Location ................ 37 4.3.2 Trigger Setting ..................38 4.3.3 Settings.....................
  • Page 4 7”/ 10.1”/ 15” S Series HMI User Manual 7.2 Problem Report Form ..................- 86 - Appendix..........................87 Appendix A: Product Specifications................87 Appendix B: HF RFID Reader Specifications ............88 Appendix C: LED Light Bar Adjustment ..............89 Appendix D: Changing Screen Resolution ............... 91...

  • Page 5: Preface

    Preface Preface Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer. Trademark Acknowledgement Brand and product names are trademarks or registered trademarks of their respective owners.
  • Page 6 7”/ 10.1”/ 15” S Series HMI User Manual Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings.
  • Page 7 Preface be easily accessible. • Keep this equipment away from humidity. • Put this equipment on a reliable surface during installation. Dropping it or letting it fall could cause damage. • The openings on the enclosure are for air convection and to protect the equipment from overheating.
  • Page 8 7”/ 10.1”/ 15” S Series HMI User Manual Caution Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. Attention Risque d'explosion si la batterie est remplacée par un type incorrect.

  • Page 9: About This User Manual

    • S Series HMI User Manual – contains detailed description on how to use the HMI device, its components and features. • S Series HMI Quick Start Guide - describes how to get the HMI up and running. Note: Some pictures in this guide are samples and can differ from actual product.

  • Page 10: Chapter 1: Introduction

    7”/ 10.1”/ 15” S Series HMI User Manual Chapter 1: Introduction This chapter gives you product overview, describes features and hardware specification. You will find all accessories that come with the HMI in the packing list. Mechanical dimensions and drawings included in...

  • Page 11: Introduction

    0BChapter 1: Introduction 1.1 Introduction The 7/ 10.1/ 15-inch S Series HMI is an elegantly-designed panel PC engineered to be the HMI that fits Smart Factory and Smart Building environments. With processing power coming from Intel® Pentium® N4200 Apollo Lake CPU, the device delivers excellent computing performance, yet low power consumption.

  • Page 12: Mechanical Dimensions

    Part No. 99KN00A00011(L) 1.4 Mechanical Dimensions This section describes appearance, connectors’ layout and mechanical dimensions of S Series HMI. Notice that this is a simplified drawing and some components are not marked in detail. Please contact our sales representative if you need further product information.
  • Page 13 0BChapter 1: Introduction ① ⑥ Description Description RJ-45 (LAN) 1 Watt Speaker ② ⑦ Two USB 3.0 2MP Front Camera (Optional) ③ ⑧ RGB LED Light Bar RS-232/422/485 ④ ⑨ (W07IP3S-PCO1AC-POE only) 3 Pin Terminal Block 12V DC HF RFID Reader (Optional) ⑤...
  • Page 14 7”/ 10.1”/ 15” S Series HMI User Manual 15-inch, R15IP3S-PCC3-POE Unit: mm Dimensions:363.4 x 277.86 x 44.5 ① ⑤ № Description № Description RJ-45 (LAN) RJ-45 (LAN/ PoE) ② ⑥ Two USB 3.0 1 Watt Speaker x 2 ③ ④...

  • Page 15: Physical Buttons

    0BChapter 1: Introduction 1.5 Physical Buttons Physical buttons and located on the top side of the HMI (Only for 15”). Icon Button Description Reset Press to reset the system Press to power on or power off the Power On/ Off device 1.6 LED Indicators: Power, Storage Power and Storage LED indicators located on the top side of the HMI (Only for 15”).

  • Page 16: Connector Description

    7”/ 10.1”/ 15” S Series HMI User Manual 1.7 Connector Description Terminal interfaces are located on the bottom side of the S Series HMI device. Note: Notice that input and output connectors vary by product size and specifications. Terminal interfaces description:...

  • Page 17: Chapter 2: Getting Started

    1BChapter 2: Getting Started Chapter 2: Getting Started This chapter tells you important information on power supply, adapter and precautions tips. Pay attention to power considerations.

  • Page 18: Powering On

    électrique quand la paume de vos mains touche à l’appareil. 2.1.2 Power Considerations The S Series HMI device operates on external DC power. Use the AC adapter included in the package. Caution Use only the AC adapter included in your package (Rating: Output 12 V/ 6.6A).

  • Page 19: Connecting The Power

    1BChapter 2: Getting Started 2.1.3 Connecting the Power Installation Instruction: Connect a 3-pin terminal block to the HMI power input connector. Connect the other side of the terminal block to the AC adapter. Connect the AC adapter to the power cord. Plug in the power cord to a working AC wall outlet.

  • Page 20: Ethernet Connector

    Power Device (PD): IEEE 802.3at (25 Watt) 2.2.3 Serial Port Connector The S Series HMI has one serial port connector to connect your HMI to external devices such as mouse, modem or printer. You can configure serial port settings via jumpers located on the motherboard.

  • Page 21: Usb Connector

    1BChapter 2: Getting Started 2.2.4 USB Connector The S Series HMI device has two USB 3.0 connectors. Use USB 3.0 connector to connect your HMI device to other USB 3.0 compatible devices. Pin assignment and connector description of USB connector.

  • Page 22: Serial Port Setting

    7”/ 10.1”/ 15” S Series HMI User Manual 2.3 Serial Port Setting You can configure RS-232/422/485 port setting of S Series HMI in BIOS. To enter the BIOS setup, you need to connect an external USB keyboard, and press Del key when the prompt appears on the screen during start up.

  • Page 23: Turning On And Off The Device

    1BChapter 2: Getting Started 2.4 Turning On and Off the Device The unit is configured to Power ON when is connected to the power source. You can Turn OFF the HMI device with the Windows power settings. To shut down the device: 1.

  • Page 24: Chapter 3: Mounting

    7”/ 10.1”/ 15” S Series HMI User Manual Chapter 3: Mounting This chapter provides mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages.

  • Page 25: Cable Mounting Considerations

    3.3 Mounting Guide S Series HMI devices come with different mounting options suitable for most of the industrial and commercial applications. The main mounting approach is rear mount - very user-friendly in terms of installation. Refer to sub-sections below for more details.

  • Page 26: Panel Mount

    7”/ 10.1”/ 15” S Series HMI User Manual 3.3.1 Panel Mount Panel mount mounting solutions is suitable for many applications where HMI should be embedded in the machine. With this mounting solution flat surface leave no bezel in the front.

  • Page 27: Vesa Mount

    2BChapter 3: Mounting 3.3.2 VESA Mount 3.3.2.1 VESA Desk Stand PCVS-V1 The S Series HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name PCVS-V1 Part No. 99KK00A0000E...
  • Page 28 7”/ 10.1”/ 15” S Series HMI User Manual 3.3.2.2 VESA Desk Stand LA-100 The S Series HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name: LA-100 Part No. 9B0000000128...
  • Page 29 2BChapter 3: Mounting 3.3.2.3 VESA Wall Mount Bracket LA-106 The S Series HMI device can be installed on a desk with the stand. You can purchase desk stand as an optional accessory. Model Name LA-106 Part No. 9B0000000412 Installation Instruction...
  • Page 30 7”/ 10.1”/ 15” S Series HMI User Manual Accessories Dimensions...

  • Page 31: Front Side Wall Mount

    2BChapter 3: Mounting 3.3.3 Front Side Wall Mount The Front Side Wall Mount is only available for 10.1” S Series HMI. You can purchase Front Side Wall Mount Bracket from Winmate. Model Name PCFW-V1 Part No. 99KK00A0000C Mounting Instruction 1. Cut a hole in the wall according to the cutout dimensions.
  • Page 32 7”/ 10.1”/ 15” S Series HMI User Manual Dimensions...

  • Page 33: Glass Wall Mount

    2BChapter 3: Mounting 3.3.4 Glass Wall Mount The Glass Wall Mounting is only available for 10.1” S Series HMI. The HMI device can be installed in a glass wall either from right side or from the left. You can purchase Winmate Glass Wall Mount Kit as an optional accessory.

  • Page 34: Chapter 4: Operating The Device

    7”/ 10.1”/ 15” S Series HMI User Manual Chapter 4: Operating the Device In this chapter you will find instructions on how to operate the HMI device.

  • Page 35: Operating System

    3BChapter 4: Operating the Device 4.1 Operating System S Series HMI support several versions of Windows OS: Windows 10 IoT Enterprise. Important: The device is shipped with the OS System according to your order. Contact us if you have any questions regarding OS settings.

  • Page 36: Volume

    4.2.5 LED Light Bar Notice that LED Light Bar is an optional feature for S Series HMI and may not be present in your device. Tap Light Bar to access the LED light bar control panel, and select Red / Green / Blue/...

  • Page 37: Performance

    4.3 Using HF RFID Reader Notice that HF RFID Reader is an optional feature for 10.1” S Series HMI and may not be present in your device. HF RFID is commonly used for ticketing, payment, and data transfer applications.

  • Page 38: Trigger Setting

    7”/ 10.1”/ 15” S Series HMI User Manual To scan the card, bring it close to the right bottom front side of device with RFID icon. Tap on the Disconnect button to stop the connection with built-in HF RFID reader.

  • Page 39: Settings

    3BChapter 4: Operating the Device • Single Scan User can also define the RFID Reader scanning as Single Scan. Under this setting, the RFID Reader will be triggered only when user click on “Send”. 4.3.3 Settings • Sound The Sound check box defines whether a beep sound will come with the data scanning. •...
  • Page 40 7”/ 10.1”/ 15” S Series HMI User Manual User can also tap on the Settings button for further details settings. Item Description Prefix User can type in this field to define the characters BEFORE the data scanned. Suffix User can type in this field to define the characters AFTER the data scanned.

  • Page 41: Rfid Output Settings

    RFID Porting Guide SDK to configure Writing Mode parameters. 4.4 Using Front Camera Notice that 2MP Front Camera is an optional feature for 10.1” S Series HMI and may not be present in your device. Note: You camera screen may differ from the pictures in thus user manual.
  • Page 42 7”/ 10.1”/ 15” S Series HMI User Manual The Camera Screen Item Description Tap to record videos Video Tap to capture photos Photo Tap to select the destination folder to save captured photos and videos, enable preview, and select picture...

  • Page 43: Shooting Photos

    3BChapter 4: Operating the Device 4.4.2 Shooting Photos 1. Open the Camera. 2. Focus on the object. 3. Tap to capture the object. 4. By default, the photo preview is displayed briefly on the screen. The preview screen automatically closes after 3 seconds. Alternatively, do one of the following: - Tap to delete the photo and return to the camera screen.

  • Page 44: Recording Videos

    7”/ 10.1”/ 15” S Series HMI User Manual 4.4.3 Recording Videos 1. Open the Camera. 2. Focus on the object. 3. Tap to record the video. The video recording screen appears. 4. Tap to stop recording and return to the camera screen.

  • Page 45: Camera Settings

    3BChapter 4: Operating the Device 4.4.4 Camera Settings 1. Tap to open the setting page. 2. Modify necessary settings. Item Description Check one of the check boxes to show the preview screen right after capturing a photo. • Show Preview: Check this box and enter the preview duration on Close preview after.

  • Page 46: How To Enable Watchdog

    7”/ 10.1”/ 15” S Series HMI User Manual 4.5 How to Enable Watchdog To enable Watchdog, you need to download Winmate Watchdog utility. Find more information about Watchdog in “Watchdog Guide” that you can download from Winmate Download Center. To enable watchdog in Watchdog AP follow the instructions below: 1.

  • Page 47: Using Recovery Wizard To Restore Computer

    3BChapter 4: Operating the Device 4.6 Using Recovery Wizard to Restore Computer Note: Before starting the recovery process, make sure to backup all user data. The data will be lost after the recovery process. Important: Before starting the recovery process, remove any expansion card.

  • Page 48: Chapter 5: Bios Setup

    7”/ 10.1”/ 15” S Series HMI User Manual Chapter 5: BIOS Setup BIOS Setup Utility is a program for configuration basic Input/ Output system settings of the HMI for optimum use. This chapter provides information on how to use BIOS setup, its functions and menu.

  • Page 49: When And How To Use Bios Setup

    4BChapter 5: BIOS Setup 5.1 When and How to Use BIOS Setup To enter the BIOS setup, you need to connect an external USB keyboard, external monitor and press Del key when the prompt appears on the screen during start up. The prompt screen shows only few seconds so need press Del key quickly.

  • Page 50: Bios Functions

    7”/ 10.1”/ 15” S Series HMI User Manual 5.2 BIOS Functions 5.2.1 Main Menu The Main menu displays the basic information about yoursystem including BIOS version, processor RC version, system language, time, and date. When you enter BIOS setup, the first menu that appears on the screen is the main menu.It contains the system information including BIOS version, processor RC version, system language, time, and date.

  • Page 51: Advanced

    4BChapter 5: BIOS Setup 5.2.2 Advanced Select the Advanced Tab from the setup menu to enter the advanced BIOS setup screen. You can select any of the items on the left frame of the screen to go to the sub menu for the item, such as CPU Configuration.
  • Page 52 7”/ 10.1”/ 15” S Series HMI User Manual 5.2.2.1 Boot Configuration BIOS Setting Description Setting Option Effect OS Selection OS Selection Enter Opens submenu...
  • Page 53 4BChapter 5: BIOS Setup 5.2.2.2 Uncore Configuration...
  • Page 54 7”/ 10.1”/ 15” S Series HMI User Manual BIOS Setting Description Setting Option Effect WBT Hook WBT Hook Configuration Enabled/ Enable/ Disabled Configuration Disabled WBT Hook RC6 (Render Check to enable render Enabled/ Enable/ Disabled Standby) standby support, R6C Disabled RC6...
  • Page 55 4BChapter 5: BIOS Setup 5.2.2.3 South Cluster Configuration BIOS Setting Description Setting Option Effect PCI Express PCI Express Enter Opens submenu Configuration Configuration settings. SATA Drives SATA Drives Enter Opens submenu settings. USB Configuration USB Configuration Enter Opens submenu settings. Miscellenaus Miscellenaus Enter...
  • Page 56 7”/ 10.1”/ 15” S Series HMI User Manual 5.2.2.3.1 PCI Express Configuration BIOS Setting Description Setting Effect Option PCI Express PCI Express Clock Enabled/ Enable/ Disable PCI Express Clock Gating Gating Enable/ Disable Disabled Clock Gating for each root for each root port...
  • Page 57 4BChapter 5: BIOS Setup...
  • Page 58 7”/ 10.1”/ 15” S Series HMI User Manual 3.2.2.3.2 Chipset-SATA Controller Configuration BIOS Setting Description Setting Option Effect Chipset SATA Chipset SATA Enabled/ Disabled Enable or Disable the Controller. Settings. Chipset SATA Controller. SATA Mode Select SATA Mode. AHCI AHCI for a system using...
  • Page 59 4BChapter 5: BIOS Setup 3.2.2.3.3 USB Pre-Port Control...
  • Page 60 7”/ 10.1”/ 15” S Series HMI User Manual BIOS Setting Description Setting Effect Option USB Per-Port USB Per-Port Control Enabled/ Control each of the USB ports Control a settings. Disabled (0~7) enable/ disable. XDCI Support Allows you to enable Enabled/...
  • Page 61 4BChapter 5: BIOS Setup 5.2.2.3.5 TXE Configuration BIOS Setting Description Setting Option Effect Target TPM Select Target dTPM Select Target TPM Device Device TPM Device...
  • Page 62 7”/ 10.1”/ 15” S Series HMI User Manual 5.2.2.3.6 Thermal Configuration Parameters BIOS Setting Description Setting Option Effect Critical Trip This value controls 125 C Select the point in which Point the temperature of the OS will shut down the the ACPI Critical Trip system.
  • Page 63 4BChapter 5: BIOS Setup 5.2.2.3.7Serial Port BIOS Setting Description Setting Option Effect Serial Port A~ Configure serial port Enabled User configuration settings. Disabled No configuration Auto EFI/ OS chooses configuration WDT count mode and Enabled/ Enable or disable WDT. counter settings. Disabled Select WDT settings.
  • Page 64 7”/ 10.1”/ 15” S Series HMI User Manual 5.2.2.3.8 WTD BIOS Setting Description Setting Option Effect WDT count mode Enabled/ Enable or disable WDT. and counter Disabled Select WDT settings. settings.
  • Page 65 4BChapter 5: BIOS Setup BIOS Setting Description Setting Option Effect WDT Count WDT Count Mode Default [Minute] Set the timeout counter to Mode [Minute]. Counter The timeout counter. Default [0] Please Set the timeout counter to change to [5] [5]. 3.2.2.3.9 Hardware Monitor...
  • Page 66 7”/ 10.1”/ 15” S Series HMI User Manual 3.2.2.3.10 General Purpose Group 0 Input/ Output BIOS Setting Description Setting Option Effect Internal Internal Resistance Push Pull User can pull internal Resistance settings resistance push-pull Open Drain User can pull internal...
  • Page 67 4BChapter 5: BIOS Setup 3.2.2.3.11 H2oUve Setup BIOS Setting Description Setting Option Effect H2oUve H2oUve Support Enabled/ Disabled Enable or Disable Support settings interface for H2oUve tool...

  • Page 68: Security

    7”/ 10.1”/ 15” S Series HMI User Manual 5.2.3.Security BIOS Setting Description Setting Option Effect TrEE Protocol TrEE Protocol 1.0 or 1.1 Version Version: 1.0 or 1.1 TPM Availability Available Availability TPM Operation No operation Operation Clear TPM Clear TPM...

  • Page 69: Power

    4BChapter 5: BIOS Setup 5.2.4 Power BIOS Setting Description Setting Option Effect CPU Configuration Enter Opens sub-menu Configuration settings...
  • Page 70 7”/ 10.1”/ 15” S Series HMI User Manual 5.2.4.1 CPU Configuration BIOS Setting Description Setting Option Effect VTX2 VTX2 mode support Enabled/ Disabled To enable or disable settings VTX2 mode support VT-d VT-d support settings Enabled/ Disabled To enable or disable...
  • Page 71 4BChapter 5: BIOS Setup 5.2.4.2 System Power Options BIOS Description Setting Option Effect Setting Intel Intel SpeedStep settings Enabled/ Allows more than two SpeedStep Disabled frequency ranges to be supported Intel Turbo Intel Turbo Boost Enabled-Enables the Boost Technology settings Performance logical processor cores on Technology...

  • Page 72: Boot

    7”/ 10.1”/ 15” S Series HMI User Manual 5.2.5 Boot BIOS Setting Description Setting Option Effect Boot Type Select Boot Type Dual/ Legacy/ Select boot type to Dual UEFI type, Legacy type or UEFI type. Quick Boot Quick Boot settings...
  • Page 73 4BChapter 5: BIOS Setup 5.2.5.1 Boot Type Order 5.2.5.2 Hard Disk Drive 3.2.5.3 Others...

  • Page 74: Exit

    7”/ 10.1”/ 15” S Series HMI User Manual 5.2.6 Exit...
  • Page 75 4BChapter 5: BIOS Setup BIOS Setting Description Setting Option Effect Exit Saving Exit Saving Setting Enter Exit system and save Setting your changes Exit Saving Exit Saving Setting Enter Save change without Setting exit Exit Saving Exit Saving Setting Enter Edit discarding changes Setting Load Optimal...

  • Page 76: Chapter 6: Driver Installation

    7”/ 10.1”/ 15” S Series HMI User Manual Chapter 6: Driver Installation This chapter describes how to install all necessary drivers.

  • Page 77: Installing Chipset Driver

    5BChapter 6: Driver Installation 6.1 Installing Chipset Driver Step 1 Insert the CD that comes with the motherboard. Open the file document “Chipset Driver” and click “infinst_auto.exe” to install driver. Step 2 Click Next to continue.
  • Page 78 7”/ 10.1”/ 15” S Series HMI User Manual Step 3 Click Yes to agree the license terms. Step 4 Click Next to install the driver. Step 5 Software setup progress window will appear, click Next to continue. Step 6 Click “Yes, I want to restart this computer now” to finish the installation.

  • Page 79: Installing Graphics Driver

    5BChapter 6: Driver Installation 6.2 Installing Graphics Driver Step 1 Insert the CD that comes with the motherboard. Open the file document “Graphics Driver” and click Setup to execute the setup. Step 2 Setup Welcome Window will appear, click Next to continue the process. Step 3 Carefully read the license terms and click Yes to agree.

  • Page 80: Installing Intel Sideband Fabric Device (Intel Mbi) Driver

    7”/ 10.1”/ 15” S Series HMI User Manual 6.3 Installing Intel Sideband Fabric Device (Intel MBI) Driver Only for Windows 8.1. Step 1 Insert the CD that comes with the motherboard. Open the file document “MBI” and click “Setup.exe” to install the driver.

  • Page 81: Installing Intel Trusted Engine Interface (Intel Txe) Driver

    5BChapter 6: Driver Installation 6.4 Installing Intel Trusted Engine Interface (Intel TXE) Driver Step 1 Insert the CD that comes with the motherboard. Open the file document “TXE” and click “Setup TXE.exe” to install the driver. Step 2 Welcome to the setup program window will appear, click Next to start the installation. Step 3 Carefully read the license terms and click Yes to agree.

  • Page 82: Installing Intel Network Connections

    7”/ 10.1”/ 15” S Series HMI User Manual 6.5 Installing Intel Network Connections User must confirm the type of operating system is being used before installing Intel Network Connections. Follow the steps below to complete the installation. Step 1 Click “PROWin64.exe”...

  • Page 83: Installing Audio Driver

    5BChapter 6: Driver Installation 6.6 Installing Audio Driver The ALC886 series are high-performance 7.1+2 channel high definition audio codecs that provide ten DAC channels for simultaneous support of 7.1 sound playback, plus 2 channels of independent stereo sound output (multiple streaming) through the front panel stereo outputs. The series integrates two stereo ADCs that can support a stereo microphone, and feature Acoustic Echo Cancellation (AEC), Beam Forming (BF), and Noise Suppression (NS) technology.

  • Page 84: Installing Usb 3.0 Driver

    7”/ 10.1”/ 15” S Series HMI User Manual 6.7 Installing USB 3.0 Driver Only for Windows 7. Note: If your operation system is Windows Embedded 8.1 Industry or Windows Embedded 8 Standard, you should skip the USB 3.0 driver installation.

  • Page 85: Chapter 7: Technical Support

    6BChapter 7: Technical Support Chapter 7: Technical Support This chapter includes the directory for technical support. Free technical support is available from our engineers every business day. We are always ready to give advice on application requirements or specific information on the installation and operation of any of our products.

  • Page 86: Introduction

    7.1 Introduction To find the Drivers and SDK, please refer to the Driver CD that comes in the package or contact us. Also, you can download drivers from Winmate Download Center. Winmate provides the following Drivers for S Series HMI:...

  • Page 87: Appendix

    Appendix Appendix Appendix A: Product Specifications Model Name W07IP3S-PCO1- W07IP3S- W10IP3S- W10IP3S- R15IP3S- PCO1AC-POE PCH2-POE PCH2AC-POE PCC3-POE Display 15" TFT (LED Size/ Type 7" TFT (Wide) 7" TFT (Wide) 10.1" TFT (Wide) 10.1" TFT (Wide) Backlight) Resolution 1024 x 600 1024 x 600 1280 x 800 1280 x 800...

  • Page 88: Appendix B: Hf Rfid Reader Specifications

    7”/ 10.1”/ 15” S Series HMI User Manual Model Name W07IP3S-PCO1- W07IP3S- W10IP3S- W10IP3S- R15IP3S- PCO1AC-POE PCH2-POE PCH2AC-POE PCC3-POE Power Specifications 12V DC Terminal 12V DC Terminal 12V DC Terminal 12V DC Terminal 12V DC Terminal Power Input Block 3 pin...

  • Page 89: Appendix C: Led Light Bar Adjustment

    Appendix Appendix C: LED Light Bar Adjustment Note: PoE Hub requires the power of more than 25 Watt. This section describes how to adjust LED Light Bar with RS-232 settings. Baud Rate 9600 Data Bits Parity: None Stop Bits Reading Version NO.
  • Page 90 7”/ 10.1”/ 15” S Series HMI User Manual Reply Value : 3 C F1 Set Success 3 B F2 Not Success *1: Checksum is 2’s complement of sum of length and all messages. Setting Function NO. Function Length Command index...

  • Page 91: Appendix D: Changing Screen Resolution

    Appendix D: Changing Screen Resolution If you plug HDMI cable from this device to an external display, touch resolution will be influenced by the external display. Follow instructions below how to adjust touch resolution. 1. Right-click mouse on the desktop, select Display Settings. 2.
  • Page 92 3. Whether to keep the display settings message appears, click Keep changes. 4. Right-click on the Windows icon and select Control Panel.
  • Page 93 5. Select Tablet PC Settings. 6. Select Setup, the window will jump out Touch this screen to identify it as the touchscreen, click the Touch and press ok.
  • Page 94 7. Go back to Display settings again, Extend these displays have been changed to Duplicate these displays, click Apply.
  • Page 95 8. Select Keep changes.
  • Page 96 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © Winmate Inc. All rights reserved.

This manual is also suitable for:

W07ip3s-pco1ac-poeW07ip3s-pco1-poeW10ip3s-pch2ac-poeW10ip3s-pch2-poeR15ip3s-pcc3-poe
