Cabling and Connector Specifications
The following table lists the media specifications for the 10/100BASE-TX line card.
Port Type
10Base-T
100Base-TX
Table 1-3 10/100BASE-TX Line Card specifications
• 802.3 standard
• RJ-45 connector wired as Media Data Interface Crossed
(MDIX); see
for pin assignments
• EIA Category 3, 4, or 5 unshielded twisted pair cabling
• Maximum 328 feet (100 meters) segment length
• 802.3u standard
• RJ-45 connector wired as Media Data Interface Crossed
(MDIX); see
for pin assignments
• EIA Category 5 unshielded twisted pair cabling
• Maximum 328 feet (100 meters) segment length
Specification
"10/100BASE-TX Line Card" on page 12
"10/100BASE-TX Line Card" on page 12
Hardware Overview
Introduction 1-13
