3.4

REMOVING AND REINSTALLING THE FAN TRAY

The Matrix E7 chassis is equipped at the factory with a removable fan tray that allows for easy
periodic cleaning and/or replacement if a problem occurs with fan operation. A flat blade
screwdriver is needed to remove and reinstall the fan tray. To remove and reinstall the fan tray,
refer to Section 3.4.1
CAUTION: The fan tray is hot swappable. However, do not run the chassis for any
extended periods of time without the fan tray, as the chassis will quickly overheat and
cause damage.
3.4.1

Removing the Fan Tray

To remove the fan tray, refer to
1. Locate the ESD wrist strap shipped with the Matrix E7 chassis. Attach the ESD wrist strap to
your wrist and plug the cable from the ESD wrist strap into the ESD grounding receptacle at the
upper right corner of the chassis.
2. Use the flat blade screwdriver to loosen the slotted screws located on either side of the fan tray.
3. Slowly slide the fan tray out of its slot in the bottom of the chassis.
and Section 3.4.2.
Figure 3-10
Removing and Reinstalling the Fan Tray
and proceed as follows:
3-17
